- Page 1 De’Longhi Dishwasher Model DEDW6015S/DEDW6015W USER GUIDE Please read this user guide carefully and retain for future reference...
-
Page 2: Table Of Contents
Contents Parts and Features ........De’Longhi Safety Precautions......Dishwasher Safety Precautions . -
Page 3: Parts And Features
Parts and Features Model: DEDW6015W/DEDW6015S 12 10 Components: 1. Cutlery Rack 7. Top Spray Arm 2. Upper Basket 8. Lower Spray Arm 3. Inner Pipe 9. Filter Assembly 4. Lower Basket 10. Inlet Pipe Connector 5. Dispenser 11. Drain Pipe 6. -
Page 4: De'longhi Safety Precautions
De’Longhi’s Safety Precautions De’Longhi pride themselves on their innovative range This appliance is designed exclusively for Ÿ of the highest quality consumer products. household use. All other uses are strictly forbidden. De’Longhi ensures all of its products are 100% safe The appliance is not intended for use by persons Ÿ... -
Page 5: Dishwasher Safety Precautions
Dishwasher Safety Precautions Your safety and the safety of others is very important. Safety messages are displayed in this manual and on your appliance. Read and obey these safety messages as they will alert you to potential hazards and tell you how to reduce the chance of injury. - Page 6 Dishwasher Safety Precautions Before the appliance is used, it must WARNING be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the When using your dishwasher, you should prevent Ÿ risk of fire, electrical shock or injury plastic items from coming into contact with the when using the appliance, follow heating element (This instruction is only applicable...
-
Page 7: Installation Safety Precautions
Installation Safety Precautions Electrical Connection Extension Cord This appliance should be properly grounded for WARNING: DO NOT USE AN EXTENSION CORD Ÿ Ÿ your safety. The power cord of this appliance is OR AN ADAPTER PLUG WITH THIS APPLIANCE. equipped with a three-prong plug which mates with standard three prong wall outlets to minimise Grounding Instructions the possibility of electrical shock. -
Page 8: Installation
Installation About the Safety Supply Hose Positioning the Appliance Position the appliance in the desired location. The Ÿ The safety supply hose consists of double walls. The back should rest against the wall behind it, and the hose's system guarantees its intervention by blocking sides, along the adjacent cabinets or walls. -
Page 9: Drain Hose Connection
Installation Water Outlet Drain Hose Connection Insert the drain hose into a drain pipe with a Connect the water drain hose. The drain hose must Ÿ Ÿ be correctly fitted to avoid water leaks. Ensure that minimum diameter of 40mm, or let it run into the the water drain hose is not kinked or squashed. -
Page 10: Using Your Dishwasher
Using Your Dishwasher QUICK START GUIDE For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programmes with pre-wash only. -
Page 11: Before Starting The Dishwasher
Using Your Dishwasher When to refill the Rinse Aid Dispenser BEFORE STARTING THE DISHWASHER If there is no rinse-aid warning light on the control The following things should be checked before panel, you can judge the amount of rinse-aid by the starting the dishwasher: colour of the optical level indicator "C"... - Page 12 Using Your Dishwasher How to fill the Rinse Aid Dispenser 1. To open the dispenser, turn the cap to the "open" (left) arrow and lift it out. 2. Pour the rinse aid into the dispenser, being careful not to overfill. 3.
- Page 13 Using Your Dishwasher Adjusting the Rinse Aid Dispenser Concentrated Detergent The rinse aid dispenser has six settings. Always start Based on their chemical composition, detergents can with the dispenser set on "3". If spots and poor drying be split in two basic types: are a problem, increase the amount of rinse aid Conventional, alkaline detergents with caustic...
- Page 14 Using Your Dishwasher Detergent Dispenser Fill the detergent dispenser with detergent. The marking indicates the dosing levels, as shown below: The dispenser must be refilled before the start of each wash cycle following the instructions provided in the Location of main wash cycle detergent. wash cycle table.
-
Page 15: Loading The Dishwasher Baskets
Using Your Dishwasher LOADING THE DISHWASHER BASKET It is not necessary to rinse the dishes under running water. Place objects in the dishwasher in following Recommendation way: Consider buying utensils which are identified as Ÿ 1. Items such as cups, glasses, pots/pans, etc. are dishwasher-proof. - Page 16 Using Your Dishwasher Loading the Upper Basket Adjusting the Upper Basket The upper basket is designed to hold more delicate The height of the upper basket can be adjusted in and lighter dishware such as glasses, coffee and tea order to create more space for large utensils both cup and saucers, as well as plates, small bowls and for the upper/lower basket.
- Page 17 Using Your Dishwasher Loading the Lower Basket We suggest that you place large items and the most difficult to clean items are to be placed into the lower basket: such as pots, pans, lids, serving dishes and bowls, as shown in the figure below. It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the top spray arm.
- Page 18 Using Your Dishwasher Cutlery Basket Damage to glassware and other dishes Cutlery should be placed in the cutlery rack Possible Causes separately from each other in the appropriate Type of glass or manufacturing process. Chemical Ÿ positions. Make sure the utensils do not nest composition of detergent.
-
Page 19: Starting A Washing Program
Using Your Dishwasher STARTING A WASHING PROGRAM Wash Cycle Table NOTE: Star ( ) means the need to fill rinse aid into the Rinse Aid Dispenser. Detergent Cycle Selection Description Running Rinse Energy Water Program pre/main Information of Cycle time(min) (Kwh) Pre-wash(45 °C... -
Page 20: Control Panel
Using Your Dishwasher CONTROL PANEL Child Lock button: Press the alt and delay Power button: To turn on/off the appliance. buttons for 3 seconds at the same time to lock the button Alt button: Dual zone wash function, press the button to select either upper basket or Display Screen: To show the remaining time, lower basket loaded. -
Page 21: Turning On The Appliance
Using Your Dishwasher TURNING ON THE APPLIANCE FORGET TO ADD A DISH? Starting a wash cycle: A forgotten dish can be added at any time before the detergent cup opens. 1. Draw out the lower and upper basket, load the dishes and push them back. -
Page 22: Care And Cleaning
Care and Cleaning Filtering System STEP 1: Turn the filter in anti-clockwise direction. The filter prevents larger remnants of food or other objects from getting inside the pump. The residue may block the filter, in this case they must be removed. Open The filter system consists of a coarse filter, a flat (Main filter) and a microfilter (Fine filter). -
Page 23: Caring For The Dishwasher
Care and Cleaning Caring for the Dishwasher To remove the upper spray arm, hold the nut and rotate the arm clockwise to remove it. The control panel can be cleaned by using a lightly dampened cloth. After cleaning, make sure to dry it To remove the lower spray arm, pull out the spray arm thoroughly. -
Page 24: Troubleshooting
Troubleshooting Before Calling for Service, review the following troubleshooting tips. Problem Possible Causes Solution Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other Dishwasher circuit breaker acted appliances sharing the same circuit with the dishwasher doesn’t start Power supply is not Make sure the dishwasher is turned on and the door is turned on... -
Page 25: Error Codes
Troubleshooting Problem Possible Causes Solution The dishes The dishes were not See notes in " Loading the Dishwasher Baskets ". are not clean loaded correctly. The program was Select a more intensive program. not powerful enough. See" Wash Cycle Table ". Not enough detergent Use more detergent, or change your detergent. -
Page 26: Help Us Help You
Help us Help You Read this guide carefully, it is intended to help you operate and maintain your new Dishwasher properly. Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call the De’Longhi Helpline. To help us provide prompt answers to your queries, please record your Dishwasher model and serial numbers. -
Page 27: Warranty Information
De’Longhi undertakes to repair or replace the Dishwasher Australia at our discretion if the product is found to be defective due www.delonghi.com.au to a manufacturing fault during the warranty period. Phone: 1800 126 659 This warranty excludes any damage caused by misuse, New Zealand neglect, shipping accident, or incorrect installation. - Page 28 P .O. Box 4540 Casula Mall, NSW 2170 P .O. Box 58-056 Botany, MANUKAU 2163 © 2017 De’Longhi Australia Pty Ltd.
