- Page 1 MANUAL DE INSTRUCCIONES INSTRUCTION BOOKLET LAVAVAJILLAS DISHWASHER LV 6041 I...
- Page 2 Attention The appliance which you have just bought is supplied not only with this instruction manual, but also with a Warranty Card Certificate, on the back of which are written the relative conditions. Please fill in the necessary details on the Card Certificate and send it to the Corberó Centre relative to the area in which the appliance is to be installed, within twenty days of the date of purchase.
-
Page 3: Table Of Contents
Contents For the user For the installer Important safety information Installation instructions Water supply connections Description of the appliance Water outlet connection The control panel Electrical connection Before use Adjusting the height of the appliance Setting the water softener The furniture door Rinse aid Fixing to the adjacent units Using your appliance... -
Page 4: Important Safety Information
Important safety information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 5: Description Of The Appliance
Description of the appliance Water hardness adjustment Levelling spacers Upper basket stop Salt container Lower spray arm Detergent dispenser Control panel Rating plate Rinse aid dispenser 10. Large filter 11. Central filter 12. Upper spray arm 13. Upper basket IN85 The control panel 1. -
Page 6: Before Use
Before use Before using your dishwasher for the first time: 1. ensure that the electrical and water connections comply with the installation instructions 2. remove all packaging from inside the appliance 3. set the water softener 4. pour 1 litre of water inside the salt container and then fill with salt 5. -
Page 7: Filling With Salt
Filling with salt Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting one of the complete washing programmes (not the Rinse and Hold programme). -
Page 8: Rinse Aid
Rinse aid Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak free drying. The dispenser, which is positioned inside the door, holds about 110 ml of rinse aid, which is sufficient for 16 - 40 dishwashing programmes, depending upon the dosage setting. -
Page 9: Using Your Appliance
Using your appliance Loading your appliance Before placing dishes in the machine, remove any scraps of food, to avoid clogging the filters and consequently reducing the performance. Do not load very small items which can fall through the baskets. The lower basket UI05 The lower basket is designed to take saucepans, lids, plates, salad bowls, cutlery etc. -
Page 10: Adjusting The Height Of The Upper Basket
The upper basket The upper basket is designed for plates (dessert plates, saucers, dinner plates of up to 24 cm in diameter), salad bowls, cups and glasses. Arrange items on and underneath the fold-down cup racks so that water can reach all surfaces. Light items (plastic bowls etc.) should be loaded in the upper basket and arranged so they do not move. -
Page 11: Use Of Detergent
Use of detergent Only use detergents specifically designed for use in dishwashers. If using powder detergents proceed as follows: Min = 15 g 1. Open the dispenser lid by pulling the catch (D). Max = 30 g 2. Add the detergent according to the recommendations in the programme chart. -
Page 12: Hints And Tips
Hints and tips To save energy Items not suitable for dishwashers Place dishes in the machine immediately after every meal and wait until the dishwasher is full before The following items should not be washed in washing. the dishwasher (unless they are sold as If necessary run the Rinse and Hold programme (see dishwasher proof): "Washing Programmes"... -
Page 13: Washing Programmes
Washing programmes Recommended quantity Programme Degree of soil Starting position Cycle Required of detergent of the programme pushbuttons description in the on the type of load selector dispenser lid dispenser Cold prewash Normal 65°C Main wash up to 65°C Normal soil. with 25 g On/Off... -
Page 14: Operating Sequence
Operating sequence Check the filters 10. At the end of the washing programme Ensure they are clean and properly positioned (see "Maintenance and cleaning"). At the end of the programme the dishwasher will automatically stop. Check that there is rinse aid and salt 11. -
Page 15: Maintenance And Cleaning
Maintenance and cleaning Internal cleaning Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend every 3 months to run a 65°C wash programme without dishes using detergen. Cleaning the central filter (After each wash) Scraps of food may accumulate in the drain filter (A) -
Page 16: External Cleaning
External cleaning Clean the external surfaces of the machine and control panel with a damp soft cloth. If necessary use only neutral detergents. Never use abrasive products, scouring pads or solvent (acetone, trichloroethylene etc..). Prolonged periods of non-operation If you are not using the machine for any period of time you are advised to: 1. -
Page 17: Something Not Working
Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. Symptom Solution The machine will not start The door has not been properly closed. -
Page 18: Service And Spare Parts
If after all these checks, the problem persists, contact your local Service Force Centre, quoting the model and serial number. This information can be found on the rating plate located on the right hand side of the dishwasher door (see picture). Prod.No. -
Page 19: Hints For Test Centres
Hints for test centres Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse aid dispenser. Test standard EN 50242 Reference programme: Normal 65°C with prewash Load: 12 standard place settings Rinse aid selector: position 5 Detergent dosage :... -
Page 20: Installation Instructions
Installation instructions Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person. Remove all packaging before positioning the machine. -
Page 21: Water Outlet Connection
Water outlet hose connection The end of the drain hose can be connected in the following ways: 1. To the sink outlet siphon, securing it if necessary with a clip. 2. To a stand pipe provided with vent-hole, minimum internal diameter 4 cm. The waste connection must be at a height of between 30 cm (minimum) and 100 cm (maximum) from the bottom of the dishwasher. -
Page 22: Adjusting The Height Of The Appliance
This dishwasher is designed to be fitted under a kitchen counter or worksurface. It is essential that the recess dimensions indicated in the diagram are followed. No further openings for venting of the dishwasher are required, but only to let the water fill and drain hose and power supply cable pass through. -
Page 23: The Furniture Door
The furniture door The door on this appliance is designed for the overlay of a panel having the following dimensions: Width 596 mm Height 644 - 724 mm max 596 max Thickness 20 mm max Weight 2 - 7.5 kg max The height of the panel depends on the height of adjacent kitchen units (see kitchen plinth adjustment). -
Page 24: Fitting The Vapour Protection
Fitting the vapour protection Fit the adhesive protection foil onto the front part of the worktop, along the entire width. Kitchen plinth adjustment II21 To allow correct opening of the door it is sometimes necessary to cut the kitchen plinth. Refer to the cutting table. - Page 25 152988 68/0 0/0699...
