Dishwasher
Instruction Manual
Instruction
Instruction
Instruction
CLV6600W/X
Manual
Manual
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLV6600W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CORBERO CLV6600W

Summary of Contents for CORBERO CLV6600W

  • Page 1 Dishwasher Instruction Instruction Manual Manual Instruction Instruction Manual Manual CLV6600W/X...

  • Page 2: Table Of Contents

    CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. •...
  • Page 3 Loading your dishwasher .……………………………………………………. Alternative basket loads …………………………………………………... • Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Getting familiar with your machine …………………………………………… Switching on the machine and selecting a programme……………..Switching on the machine…………………………………………………. • Programme follow-up ……………………………………………………… • Changing a programme …………………………………………………… •...
  • Page 4 Active Drying Unit: This system provides better drying performance for your dishes. Worktop Rating plate Upper basket with racks Control Panel Upper spray arm Detergent and rinse-aid dispenser Lower basket Cutlery basket Lower spray arm Salt dispenser Filters Upper basket track latch...

  • Page 5: Technical Specifications

    Technical specifications Capacity 1 place settings Height 850 mm Height 820 mm (without worktop) Width 598 mm Depth 598 mm Net Weight 46 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W...

  • Page 6: Safety Information And Recommendations

    SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling.
  • Page 7 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
  • Page 8 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.

  • Page 9: Recommendations

    For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •...

  • Page 10: Items Not Suitable For Dishwashing

    Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers.

  • Page 11: Water Connections

    Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning.

  • Page 12: Water Inlet Hose

    Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection.

  • Page 13: Water Outlet Hose

    Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink.

  • Page 14: Electrical Connection

    Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur.

  • Page 15: Fitting The Machine Undercounter

    Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
  • Page 16 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product  Without Insulation With Insulation  All Product  For 2nd Basket For 3rd Basket  Height 820 mm 830mm 835 mm Warning: After removal of worktop, the machine should be placed in such a closed place of which dimensions are shown at fig.

  • Page 17: Prior To Using The Machine

    IF AVAILABLE Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •...

  • Page 18: Testing Strip

    Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available).
  • Page 19 Adjust water hardness setting of your machine according to the level specified on the test track. Push the Programme selection button and hold down. In the meantime, energize the machine by pushing ON/OFF button. Hold down the programme selection button until “SL” on the screen goes off. After “SL”...

  • Page 20: Detergent Usage

    Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children.

  • Page 21: Filling With Rinse Aid And Making The Setting

    Recommended usage: If you want to obtain better results while using combined detergents, add salt and rinse aid into your machine and adjust the water hardness setting and the rinse aid setting to the lowest position. Solubility of the tablet detergents produced by different companies can vary depending on the temperature and time.

  • Page 22: Loading Your Dishwasher

    Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag. LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance.
  • Page 23 Top basket height adjustment while it is full Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed.

  • Page 24: Alternative Basket Loads

    Alternative basket loads Lower Basket Top Basket...
  • Page 25 Faulty loads   Important Note for Test Laboratories   For detailed information on performance tests, please contact following address:   "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.  ...

  • Page 26: Programme Descriptions

    PROGRAMME DESCRIPTIONS Programme No Delicate Intensive Quick 40 ° C 30 min. Super 50 min. 65 ° C Prewash Programme names and 40° C 50° C 35° C 40° C 65° C 65° C temperatures soups, sauces, pasta, Type of food waste Fresh less d rty, co ee, cold meats, cold meats,...

  • Page 27: Getting Familiar With Your Machine

    GETTING FAMILIAR WITH YOUR MACHINE 1.) ON/OFF Button When pressed on ON/OFF button, the machine is energized and the light on Start/Standby button goes on. 2.) Extra Hygiene Button By using this option, washing temperature and periods during respective cycles may be changed, which ensures more hygienic washing. 3.) Tablet Detergent Button Push Tablet Detergent button when using combined detergent that contains salt, rinse aid and extra functions.
  • Page 28 7.) Start/Pause Button Once you press the Start/Pause button, the programme you selected with the programme selector button will start running and the status indicator lamp “wash” will light up.In the stop condition while wash led is On, Start/Pause led will blink. 8.) Salt Lack Warning indicator In order to see whether softening salt in your machine is sufficient or not, check salt lack warning light on the display.When salt light...

  • Page 29: Switching On The Machine And Selecting A Programme

    SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine The lamp on Program Start/Pause key goes off once the Program starts and the washing lamp is highlighted. Press the Power On/Off key. Select the program suiting your dishes via the Program Selector button.

  • Page 30: Changing A Programme With Resetting

    Changing a programme with resetting If you would like to cancel a program while a washing program is resumed. Hold Start/Pause button pressed for approx. 3 sec. until Finish light blinks. Once Finish light comes on, it means that the cycle has been cancelled.

  • Page 31: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine.

  • Page 32: Spray Arms

    Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left.

  • Page 33: Failure Codes And What To Do In Case Of Failure

    FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR DESCRIPTION CONTROL • Make sure the water input tap is totally open and that there is no water cut. Inadequate water supply Close the water input tap, separate the water input hose from the tap and clean the filter at •...
  • Page 34 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.

  • Page 35: Practical And Useful Information

    If the dishes won't dry up A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. • If there are rust stains on the dishes Stainless-steel quality of the dishes washed is insufficient. •...
  • Page 36   THE PRODUCT FICHE (Spect)  Supplier's trade mark  CORBERO   Supplier's model  CLV6600W/X Capacity of dishwasher  12  The energy efficiency class  Annual energy consumption in kWh per year (AE ) ( 280 Cycle ) * Energy consumption (E ) (kWh per cycle)  0,90 Off­mode power consumption (W) (P )  0,50  Left­on mode power consumption (W) (P )  1,00   3360 Annual water consumption in litres per year (AW )  ( 280 Cycle ) ** Drying efficiency class ***   Standard programme name **** Eco    Programme time for standard cycle ( min)  Noise dB(A)  Freestanding/Built-in  Freestanding     * Energy consumption 258 kwh per year, based on 280 standard cleaning cycles using cold water fill and the consumption    of low power modes. Actual energy consumption will depend on how the appliance is used.  ** Water consumption 3360 liters per year based on 280 standard cleaning cycles. Actual water consumption will depend ...
  • Page 37 52253493 R35...
