Generac Power Systems 00941-4 Owners And Installation Manual page 41

ITEM PART NO.
1 091526
2 020093
3 0E7556
4 075477
5 051716
6 074908
7 023484M
8 0A8592
9 049226
10 075476
11 051715
12 022985
13 023897
14 0E7557
15 030809
16 087798
17 092113
18 0A9611
19 032300
20 0A6422
21 065795
22 022264
23 0E7555
24 096874
25 0A6060
26 043181
27 043182
28 089744
29 0A6423A
30 045756
31 086722
32 075210A
33 0A6423B
34 0912970025
35 0A6470
36 091269A
37 023484D
38 082121A
39 051713
40 025105
41 084867
42 051718
43 0C1457
44 036933
45 0A6423C
46 029333A
47 023762
48 0D4885
49 051714
50 0A6464
51 0D4884
52 0D4882
53 0A6700
54 0A9183
Section 6 — Exploded Views and Parts Lists
IMPACT-36 plus II Recreational Vehicle Generator
QTY. DESCRIPTION
7 M5-0.8 X 12MM PHILLIPS PAN HD. MACH. SCR.
1 BOX, CONTROL TOP
1 BOX, CONTROL PANEL
1 SCREW PPHM M5-0.8 X 20
1 M5-0.8 HEX NUT
8 TAPTITE M5- .8 X 10MM
1 SNAP BUSHING
1 CIRCUIT BREAKER,15A.
6 LOCK WASHER-M5
10 M4-0.7 X 16MM
2 M4-0.7 HEX NUT
4 M4 FLAT WASHER
7 M5 FLAT WASHER
1 CONTROL PANEL, FRONT
1 RUBBER GROMMET
1 SWITCH, SPDT ROCKER
1 SWITCH, SPDTMOM ROCKER
1 FUSE, 7.5A. AGC
1 FUSE HOLDER
1 EXTRUSION, CONTROLLER
1 RECTIFIER, BATTERY CHARGE
14 LOCK WASHER-M4
1 PANEL DECAL
4 DIODE, DUAL 30A
1 ASSEMBLY, PCB CCG
4 PHMS M3-.05 X 10MM
4 LOCK WASHER-M3
1 RESISTOR, POWER 1 OHM
2 BUS BAR, OUTER
4 TAPTITE M6- 1.0 X 10MM
1 BRACKET, HEAT SINK-PCB
1 TERMINAL BLOCK
4 BUS BAR, INNER
1 GROUND WIRE
1 DC POWER HARNESS
1 REMOTE PANEL HARNESS
1 SNAP BUSHING
1 CLAMP, CONTROL PANEL HARNESS
2 WASHER FLAT M5
4 #6-32 X 1/4" PHILLIPS ROUND HD. MACH. SCREW
3.5 RUBBER U-CHANNEL
4 M4-0.7 X 10MM HEX HEAD CAPSCREW
1 HOUR METER
4 PPHMS 10-32 X 3/8" LG
1 BUS BAR, CENTER
1 BLACK TIE WRAP, 7" LG
4 SHAKEPROOF EXT. #10
1 INVERTER ASSEMBLY
2 M3-0.5 NUT
1 WIRE HARNESS-HEATSINK TO PCBI
1 WIRE HARNESS
1 HARNESS-PCBI TO PANEL (NOT SHOWN FOR CLARITY)
1 HARNESS-HEATSINK TO TERM. BLOCK (NOT SHOWN FOR CLARITY)
1 HARNESS, CONTROL PANEL (NOT SHOWN FOR CLARITY)
Control Panel – Drawing No. 0E7560
Generac ® Power Systems, Inc. 39
