Generac Power Systems QuietSource 005028-0 Owner's Manual page 56

19
26
6
ITEM PART NO. QTY.
1 0E9769 REF
0F0779 REF
0E9769A REF
2 0E9837
3 0F0123
4 0F0118
5 099502
6 0C2454 REF.
7 052250
8 022097
9 022473 12
10 022127
11 046627
12 060035
14 0F0127
54
Section 8 - Exploded Views and Parts Lists
Liquid-cooled 15, 20 and 25 kW Generators
Radiator — Drawing No. 0E9965-F
1
18
18
7
25
9
DESCRIPTION
SUPPORT RADIATOR 2.5L FORD
SUPPORT RADIATOR 2.5L AL
SUPPORT RADIATOR 2.5L FORD
ALM
1 RADIATOR 2.5L FORD
1 VENTURI 16" FAN 2.5L FORD
1 GUARD FAN 2.5L FORD
4 CLAMP HOSE #24 B1.06-2.00
SCREW THF M6-1 X 16 N WA Z/JS
2 TAPE FOAM 1 X 1(21" LG)
8 WASHER LOCK M6-1/4
WASHER FLAT 1/4 ZINC
8 NUT HEX 1/4-20 STEEL
1 CAP RADIATOR
4 SPACER .41 X .75 X .87 ST/ZNC
1 HOSE, UPPER RADIATOR 174MM
TAL
5
11
12
2
5
9
8
10
5
5
7
15
16
17
ITEM PART NO.
15 0E9833
16 035461
17 069860C
18 0A7275
19 031669
20 065852
21 0A2111
24 0C2454
25 022287
26 077992
27 050275
14
TO THERMOSTAT
ADAPTER
TO BASE OF
WATER INLET
TUBE (ON BLOCK)
20
21
27
9
8
10
QTY. DESCRIPTION
1 HOSE, 2.5L FORD LOWER
RADIATOR
1 BARBED STR 1/4 NPT X 3/8
1 HOSE OIL DRAIN ASSY 21"
4 FOAM 1.5 X 1 ADHESIVE BACKING
(21.5" LG)
4 BOLT CARR 1/4-20 X 1-3/4 JS500
1 SPRING CLIP HOLDER .37-.62
1 SCREW SWAGE 10-32 X 5/16 Z/YC
6 SCREW TH-FRM M6-1 X 16 N WA
Z/JS
4 SCREW HHC 1/4-20 X 3/4 G5
REF NUT HEX LOCK M6-1.0 SS NY INS
2 DECAL WARNING-FAN
24
3
27
4
24
