GENERAL

• Frequency coverage

• Mode

• No. of operating Ch.

• Power supply requirement : 7.2 V or BP-222N

• Current drain

• Operating temp. range

• No. of CTCSS freq.

• Dimensions

(projections not included)

• Weight (approx.)

TRANSMITTER

• Output power

• Ext. mic. connector

RECEIVER

• Sensitivity

• Audio output power

(at 7.2 V DC)

• Ext. speaker connector

All stated speciﬁcations are subject to change without no-

tice or obligation.

SPECIFICATIONS

: 446.00625–446.09375 MHz

: F3E (FM)

: 8 (simplex)

: 0.6 A approx.

: –25˚C to +55˚C

: 38

: 54(W) × 128(H) × 37(D) mm

: 317 g (including BP-222N)

: Less than 500 mW ERP

: 3-conductor 2.5 (d) mm/2.2 kΩ

: Less than 26.5 dBµV/m

(20 dB SINAD)

: More than 500 mW at 5%

distortion with an 8 Ω load

: 2-conductor 3.5 (d) mm/8 Ω
