Related Manuals for NewAir AW-321ED
Summary of Contents for NewAir AW-321ED
- Page 1 Owner’s Manual 32 Bottle Thermoelectric Wine Cooler Model: AW‐321ED Please read and save these instructions. ...
-
Page 2: Parts List
PARTS LIST 1. Interior Light 2. Fan Mask 3. Shelves 4. Leveling Feet 5. Door Hinge 6. Temperature Display 7. Temperature Buttons 8. Door Frame 9. Glass Door 10. Door Handle IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock, or injury when using your appliance, follows these basic precautions; • Carefully read all instructions before using this wine cooler for the first time. • DANGER – RISK OF CHILD ENTRAPMENT: An empty wine cooler can be dangerous to children. Remove any latches, lids, locks, and/or doors from unused or discarded appliances to prevent child entrapment and suffocation. • Never allow children to operate, play with or crawl inside this appliance. • Do not clean the appliance with flammable fluids or corrosive chemicals. The fumes can cause a fire or an explosion. • Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other appliances. The fumes can cause a fire or an explosion. •... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Wine Cooler • Remove exterior and interior packing materials. • Make sure the following parts are included with the appliance: ‐ 14 slide‐out shelves ‐ Instruction manual • Before connecting the wine cooler to a power supply, let it stand upright for approximately 2 hours. This will reduce the possibility of malfunction that may have occurred from handling or transport. • Before using this wine cooler for the first time, clean the interior with a soft cloth and lukewarm water. • Place the appliance on a level floor surface that will be strong enough to support it when it is at full capacity. To level the wine cooler, adjust the front leveling feet located at the bottom of the appliance. • Keep this wine cooler away from direct sunlight and excess heat sources such as stoves, heaters, radiators, etc. Direct sunlight may damage the unit’s acrylic coating while heat may increase electricity consumption. Extreme hot or cold ambient temperatures may also affect performance. • PLEASE NOTE: This wine cooler is only designed for home use. Do not use it in a garage or basement. ELECTRICAL PRECAUTIONS Warning Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Products service center. • This unit should be properly grounded for your safety. The power cord is equipped with a 3‐prong plug which is compatible with 3‐prong wall outlets. This is to minimize the possibility of electrical shock. Do not, under any circumstances, cut or remove the ground wire from the supplied power cord. • Do not use an extension cord with this appliance. • This unit requires a standard 110V ~ 60Hz electrical outlet with a 3‐prong plug. • To prevent accidents and/or injury, the power cord should be secured behind the wine cooler and not left exposed or dangling. ... -
Page 4: Operating Your Wine Cooler
OPERATING YOUR WINE COOLER • For optimal performance, it is recommended that you keep the wine cooler in a place where the ambient temperature is between 50 ‐ 80°F (10 ‐ 26°C). If the ambient temperature is above or below the recommended temperature range, the unit’s performance may be affected. Using the wine cooler in extremely cold or hot conditions may cause interior temperatures to fluctuate, and as a result, the ideal range of 50 ‐ 60°F (10 ‐ 16°C) may not be reached. • The temperature may also fluctuate depending on whether the interior light is on and whether the bottles are located on the upper, middle or lower racks. Adjusting the Temperature and the Interior Light: • Press the buttons on the display panel to turn on the interior light and to set the temperature. • The two buttons on the panel ‐ “ ” and “ ” ‐ adjust the temperature in increments of 1°F between 46 ‐ 66°F. You can also switch the interior light on or off by pressing the “ ” button. CARE AND MAINTENANCE Cleaning YourWine Cooler • Unplug the wine cooler from the power supply and remove any wine bottles from the unit. • Clean the inside of the wine cooler with a warm water and baking soda solution. The solution should consist of 2 tablespoons of baking soda to one quart of water. • Clean the outside of the wine cooler with mild detergent and warm water. • Remove the water reservoir from the bottom of the unit and rinse it with water. Transporting YourWine Cooler • Remove all bottles from the unit. • Securely tape down the shelves inside the wine cooler. • Screw the leveling legs up to the unit’s base to avoid damage. • Tape the door shut. • Make sure the wine cooler stays in an upright position during transportation. ... -
Page 5: Troubleshooting
TROUBLESHOOTING Many common wine cooler problems can be easily solved, saving you the cost of a possible service call. Try the suggestions below to see if you can solve your problem before calling customer service. PROBLEM: POSSIBLE CAUSES: • The wine cooler does not operate. The unit is not plugged in or may be plugged in using a different voltage. • The circuit breaker may be tripped or there may be a blown fuse in your home. • Check the unit’s temperature control settings. • The external environment may be too hot. • The wine cooler does not get cold The door is being opened too often. • enough. The door is not closed completely. • The door seal does not seal properly. • The wine cooler does not have the correct clearances. • The internal light does not work. Call customer service. • The unit is vibrating. Make sure the wine cooler is placed on a level floor surface. • The wine cooler is making too much The wine cooler is not leveled. • noise. Check the unit’s fan. • The wine cooler is not leveled. ...
