Addonics Technologies AE25SN35SA Installation Manual

Installation Guide

Front View

Casing
Removable drive
tray

Rear View

15-pin SATA
power connector

How to remove the drive tray from the casing

Push the 2 latches inward then pull out the drive tray.
Latches
ADDONICS TECHNOLOGIES
Model: AE25SN35SA
Screw mounting
holes
7-pin SATA data
connector

How to mount the drive on the tray

Step 1
Step 2. Pull the clips outward to secure the drive
Step 3

TECHNICAL SUPPORT

Email: http://www.addonics.com/sales/query/
Internet: http://www.addonics.com
Technical Support (8:30 am to 6:00 pm PST)
Phone: 408 453-6212
Email: http://www.addonics.com/support/query/
