1.2.11 Connectors, with Standard I/O

The standard I/O connectors are located on the backplane of the controller, identified below.
AC
Power
In
THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU'S PRIOR WRITTEN CONSENT.
Overview
Revision 1.0 - June 1, 2012
Audio
Cash
drawer Line Out
GND
Cash Drawer
24V
(1 or 2)
PUSB
(usually
printer)
12V PUSB (VFD, Monitors,
or other 12V power)
LAN
USB
(x2)
Chapter 1 - Overview
TeamPoS 7000 F-Series Peripherals - 11
PCI
Express
Unused
slot
VGA
out
