Memory-map Adventurer 3500 User Manual page 13

the Maps folder to select it and then click OK to send the map to the device.
3) Important – Safely remove the 3500 from your PC by right-clicking on the drive in Computer and
selecting Eject from the menu. If you are using Windows XP you will need to use the Safely Remove
Hardware option in the system tray to remove the device. Not doing so could corrupt the card data making
it unusable.
Method 2 – Sending the visible map portion on screen
If the map you want to send is over 400MB in size, or you only want to send a portion of it to the GPS then
please follow the steps below.
1) Exit Memory-Map on the 3500 if it is running by tapping the Exit button and then connect your
Adventurer 3500 to your PC with the supplied USB cable. Tap the Press to Connect button on the screen
and the 3500 will be seen by your PC as a removable drive.
2) In Memory-Map on your PC open the map you wish to send and move to the area you require. You can
zoom in or out to adjust the area until you are happy you have the area covered.
3) Click Mobile Device > Send Visible Map Portion...
A window similar to the one below will appear
If you wish to give map a name type this into the Name box.
Click the Storage card on PC button and then the button.
In the Browse for Folder window choose the Removable Drive that contains the SD card inside the unit. It
can be easily identified as it will contain a number of Memory-Map folders and a Userdata folder. Double-click
the Maps folder to select it and then click OK to send the map to the device.
4) Important – Safely remove the 3500 from your PC by right-clicking on the drive in Computer and
selecting Eject from the menu. If you are using Windows XP you will need to use the Safely Remove
Hardware option in the system tray to remove the device. Not doing so could corrupt the card data making
it unusable.
