11. Internal I/O Connectors
•
1x PCI Express x16 slot
•
3x PCI Express x1 slots
•
2x PCI slots
•
1x Floppy port supports up to 2.88MB
•
2x Ultra DMA 33/66/100/133 connectors (AX8-V)
•
3x Ultra DMA 33/66/100/133 connectors (AX8-3
•
4x SATA 150 Connectors (AX8-3
•
2x SATA 150 Connectors (AX8-V)
•
2x USB 2.0 headers
•
1x IEEE 1394 header (AX8-3
•
1x FP-Audio header
•
1x CD-IN header
12. Back Panel I/O
•
1x PS/2 keyboard, 1x PS/2 mouse
•
1x Serial port connector, 1x Parallel port connector
•
1x S/PDIF In connector (AX8-3
•
1x S/PDIF Out connector (AX8-3
•
1x AUDIO1 connector (Rear-Left / Rear-Right, Center/Subwoofer)
•
1x AUDIO2 connector (Mic-In, Line-In, Front-Left/Front-Right)
•
4x USB 2.0 Connectors
•
1x IEEE 1394 Connector (AX8-3
•
1x RJ-45 LAN Connector
13. Miscellaneous
•
ATX form factor: 305 x 245 mm
14. Order Information
Model
rd
AX8-3 Eye
AX8
AX8-V
Specifications and information contained herein are subject to change without notice.
AX8 Series
rd
rd
Eye/AX8)
rd
Eye/AX8)
rd
rd
Features
4x SATA RAID 0/1/0+1 ports, 3x PATA ports, IEEE1394, S/PDIF,
GuruClock
4x SATA RAID 0/1/0+1 ports, 3x PATA ports, IEEE1394, S/PDIF
2x SATA RAID 0/1 ports, 2x PATA ports
rd
Eye/AX8)
Eye/AX8)
Eye/AX8)
Eye/AX8)
Chapter 1
