3.Operation
3.3.5. Print Setup Options
Click menu "3D Print->Setup". The following dialog box pops up:
Print Options
Predef: Sets the print resolution (layer thickness) of the printer. This can be between
0.2mm per layer to 0.4mm per layer (depending on the printer model).
Optimize: Disabled.
Height Options
Base: This is the thickness of the raft of material before the support layer is printed
under the part. When the printer starts printing, it first prints a raft of non-solid
material in which all the lines of support material are horizontal (along the Y axis). It
keeps building up horizontal rows of support material for as many mm as you have
chosen. Then, just before it gets to the bottom surface of the real part, it starts to build
UP! 3D Printer User Manual
26
