Summary of Contents for Electrolux ERS8997B
- Page 1 Kyl--Frysskåp / Køle--Frysskab / Fridge--Freezer BRUKSANVISNING BRUGSANVISNING INSTRUCTION BOOK ERS8997B 818 17 20--02/3...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ERS8997B Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg holder Bottle shelf Freezer plate Freezer drawer Ventilation grille Freezer calendar Quick store Booklet for screen is included in the cabinet Control Panel... -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 30 minutes, or for 4 hours if it was transported horizontally. -
Page 5: Measuring The Temperature
Measuring the temperature If the temperature is measured using a standard, single thermometer, this should be put in a glass of water centrally placed inside the cabinet. This will reflect the temperature inside the food products. Do not place the thermometer hanging or lying directly on the shelf. -
Page 6: Cabinet Interior
Cabinet interior The shelves and door compartments are removable and can easily be re-arranged. Certain shelves must be lifted up by the rear edge to enable them to be removed. The lower door compartment and the glass shelf above the vegetable drawer must not be moved. They are required for proper air circulation inside the cabinet. -
Page 7: Temperature Inside The Freezer
Temperature inside the freezer To ensure that foodstuff will keep for a long time, be sure that the temperature inside the freezer is -18°C or below. Please note, however, that the energy consumption increases as the temperature decreases. The built-in temperature display shows the warmest temperature inside the freezer. -
Page 8: Freezing
Temperature memory The temperature memory shows when an alarm has been triggered in the cabinet. The temperature memory operates as follows: When the temperature inside the freezer again falls below -11°C the audible alarm stops. The - 18 temperature display and the red warning lamp will flash to indicate than an alarm was triggered. -
Page 9: Suitable Storage Periods
· Do not freeze too much food at the same time. The freezing capacity of the unit is indicated in the specifications section. Suitable storage periods Food purchased in frozen condition: Follow the advice on the maximum storage period indicated on the packaging. -
Page 10: Hints And Tips
Hints and Tips Saving energy Food Storage · Pay careful attention to where the cabinet is · To obtain the best results from your appliance, placed. See the section "Installation". When neither hot foods nor liquids which may installed correctly, the cabinet will consume less evaporate, should be placed in the larder energy. -
Page 11: Cleaning
Cleaning Clean the cabinet at regular intervals. Don't use detergents, abrasive powders, high perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol when cleaning the product Disconnect the appliance from electricity supply. Internal Cleaning Clean the inside and accossories with warm water and bicarbonate of soda (5ml to 0,5 litre water) Rinse and dry thoroughly. -
Page 12: Defrosting The Freezer
Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm. Remove the freezer drawers and place them on top of each other by turning every other drawer one half turn. -
Page 13: Something Not Working
Something Not Working Before contacting your local Service Force Centre check the following point: Problem Possible cause / Remedy " " is displayed in the temperature An error has occurred in measuring the temperature. Call your display. service representative. (The cooling system will continue to keep food products cold, but temperature adjustment will not be possible.) The yellow Action Freeze and red... -
Page 14: Customer Care Department
Too much frost and ice are produced. Make sure that the door is completely closed and that the insulating strip is complete and clean. Set a warmer temperature. The compressor operates continuously. Set a warmer temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. -
Page 15: Technical Specification
Technical specification ERS8997B Model Gross volume, refrigerator 228 l freezer 124 l 595 mm Width 2000 mm Height 600 mm Depth 372 kWh/year Energy consumption Energy class 160W Rated power 12 kg/24 hours Freezing capacity Installation Unpacking Unpack the cabinet and check that it is in good condition and free of any transport damage. -
Page 16: Installing The Cabinet
Installing the cabinet To obtain the best performance from the cabinet, ensure : · the cabinet is placed in a dry, cool place and is not exposed to direct sunlight. · the cabinet is not placed close to a source of heat, e.g. - Page 17 bäÉÅíêçäìñ=dêìééÉå=Éê=îÉêÇÉåë=ëí›êëíÉ=éêçÇìÅÉåí=~Ñ=ÉåÉêÖáÇêÉîåÉ=éêçÇìâíÉê=íáä=â›ââÉåJ=êÉåÖ›êáåÖëJ=çÖ=ìÇÉåÇ›êë ÄêìÖK=aÉê=ë‹äÖÉë=™êäáÖí=çîÉê=RR=ãáääáçåÉê=éêçÇìâíÉê=Ñê~=bäÉÅíêçäìñ=dêìééÉå=EÄä~åÇí=~åÇÉí=â›äÉëâ~ÄÉI=âçãÑìêÉê î~ëâÉã~ëâáåÉêI=ëí›îëìÖÉêÉI=ãçíçêë~îÉ=çÖ=éä‹åÉâäáééÉêÉF=íáä=Éå=î‹êÇá=~Ñ=Å~K=âêK=NMM=ãáääá~êÇÉêK=mêçÇìâíÉêåÉ=ë‹äÖÉë=á ãÉêÉ=ÉåÇ=NRM=ä~åÇÉ=îÉêÇÉå=çîÉêK qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK MARIESTAD DA--MJ...
