Installation
Guide
And
Owner's
Manual
Model:
CD30
CD36
READ
AND
SAVE
THIS
INSTRUCTION
MANUAL
Important: When receiving and unpacking, note
any damage on the freight bill. Any damage
claim must be filed with the carrier.
Power pack is separate – do not lose.
ESSICK AIR PRODUCTS
5800 Murray Street, Little Rock, AR 72209
800-643-8341
Purchased From:______________________
Date of Purchase:_____________________
Manual #: 70790
Advertisement
Related Manuals for Essick CD30
Summary of Contents for Essick CD30
- Page 1 CD30 CD36 READ SAVE THIS INSTRUCTION MANUAL ESSICK AIR PRODUCTS 5800 Murray Street, Little Rock, AR 72209 800-643-8341 Purchased From:______________________ Important: When receiving and unpacking, note any damage on the freight bill. Any damage Date of Purchase:_____________________ claim must be filed with the carrier.
- Page 2 2. Ensure that the roof or stand is strong enough to support the cooler. Operating weight, when the cooler is full of water, is significantly heavier than shipping weight. CD30 operating weight: 1538 lbs. CD36 operating weight: 1588 lbs. 3. The cooler must be located so that it has a constant supply of fresh air. The cooler does not recirculate air.
- Page 3 3. The gauge of the wire used must be suitable for the voltage, horsepower, and length of the wire. 4. For motors up to and including 2 H.P. 240V single phase, use Essick Six (6) Position Wall Switch, part number ECR-6. 5. For larger motors and all three phase applications, the proper motor starters must be used to control the motor.
- Page 4 5. There are 2 pads used in each louver of the CD30 (one aspen and one filter) and 3 pads used in each louver of the CD36 (one aspen and two filters).
- Page 5 Suggested Cooler Curb Design ROOF OPENING 1. 2x12 CONSTRUCTION 2. ALL TOLERANCES ±1/8" 3. ROOF OPENING 46" X 70" Replacement parts...
-
Page 6: Limited Warranty
For five years from date of installation, we will replace the original base assembly if water leakage should occur due to rust out. For one year from date of installation, we will replace any original component provided by Essick Air Products Inc., which fails due to any defect in material or factory workmanship only.
