Whole-Home Lighting Control
GE Smart Remote Plus Transmitter
RF 2000 KINPS
IMPORTANT: Make sure all your GE Smart Remote Plus DEVICES are
set to the same HOUSE CODE setting (check back of unit).
Time Set Mode
1. Move slide switch to time set position.
2. Toggle master control to select current day. Press set once.
3. Toggle master control to select current hour. Press set once.
4. Toggle master control to select current minute. Press set once.
5. Toggle master control to select current day period: A(am) or P(pm).
Programming the Whole-Home Lighting Control
1. Move slide switch to prog set position.
2. Toggle master control to place flashing arrow next to program
you want to set/adjust. Press set once.
3. Press master control + to activate, and – to deactivate current
program. Only active programs run in auto mode Press set once.
4. Toggle single channel switches and master control to select and
/or deselect program channels. Press set once.
5. Toggle master control to select day combination. Press set once.
6. Toggle master control to select ON hour. Press set once.
7. Toggle master control to select ON minute. Press set once.
8. Toggle master control to select ON am or pm. Press set once.
9. Repeat steps 5-7 for OFF time.
10. Toggle master control adjust another program or move slide
switch to auto or man position. Press set once.
FCC ID:
QOB########
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference, including interference that may cause undesired operation.
Vacation Mode
1. To enable: move slide switch to prog set position.
Press vacation button until Vac appears on LCD.
2. Follow steps 2-10 of Programming Whole-Home Lighting Control
section to change vacation programs.
3. To disable: move slide switch to prog set position.
Press vacation button until Vac icon disappears.
Operating the Whole-Home Lighting Control
In auto mode, channels can be controlled BOTH manually and
with timer programs. In man mode, timer programs are deactivated
and channels can ONLY be controlled using toggle switches.
For manual operation:
1. Toggle master control switch to ALL channels simultaneously.
2. Toggle single channel switches to control channels individually.
LCD icons will appear (disappear) for channels which are
turned ON (OFF).
IMPORTANT: Test range operation frequently. Channel icon
will appear on LCD even though Receiver may be out of range.
Move Receiver(s) and Whole-Home Lighting Control as close
together as possible for best results.
Made in China
Date:
