Bottom View

1. Ventilation slots
2. RAM compartment
3. Battery release button
4. Battery pack
4
3

LED Status Indicators

The status indicators in the upper left corner of the keyboard light up when a particular function of the
computer is active. Each indicator is marked with a symbol.
Optical Drive
Number-Lock
Caps-Lock
Scroll-Lock
The computer is reading information from the
optical drive.
The computer is reading from, or writing to the
HDD
built-in hard disk.
The keyboard is in Num-Lock mode.
The keyboard is in Caps-Lock mode.
The keyboard is in Scroll-Lock mode.
12 of 48
1
2
