Westerbeke 5.5 BCD-614 Specification

A truly low profile 5.5 kilowatts...
5.5/5.0 BCD Diesel Generator
Quiet and Compact
Operating at 1800-rpm with a tuned air intake
silencer and four point vibration mounts, the 5.5 BCD
runs smooth and quiet. Designed specifically for
those installations where height is extremely limited,
this generator also has one of the smallest envelopes
available in its class.
Powerful, Lightweight and Reliable
The 5.5 BCD is powered by an industrial .95 liter
engine supplying a full 5.5 kilowatts. The 5.5 BCD
continues to support the strong record of reliability
Westerbeke has built supplying generators to the
United States Navy and Coast Guard as well as com-
mercial vessels and pleasure craft.
Easy Operation and Maintenance
To minimize engine maintenance, the 5.5 BCD
operates at a slow 1800-rpm and is fresh water
cooled for longer life. Easy access to all servicing
points and individually removable top and side
panels of the optional sound enclosure allow easy
installation and maintenance.
Full Torque, Power Take-Off Interface
A customer sourced, electric clutch and hydraulic
pump can be mounted to the full torque, power take-
off interface for use with such items as bow or stern
thrusters, compressors, winches and emergency
"get-home" systems.
Five Year Limited Warranty
The 5.5 BCD is backed by Westerbeke's 5-year
limited warranty. The presence of Westerbeke in over
65 countries around the world provides customers
with easy access to parts, service and technical sup-
port worldwide. Established in 1937, Westerbeke is
committed to providing its customers with quality
products and unequaled after sales support.
DIESEL
GENERATOR
5.5/5.0 BCD Diesel Generator
Standard Features
Instrument panel and safety stop switch
Remote start-stop plug-in connection
Extra oil pressure switch for remote signal
or control functions
Safety shut-downs - high coolant temperature,
low oil pressure, high exhaust temperature
A.C. circuit breaker
17 amp battery charger
Power take-off interface
Self-bleeding fuel system
Fresh water cooling and coolant recovery tank
45 degree water injected exhaust elbow
Gear driven raw water pump
Tuned air intake silencer
Vibration mounts - fail safe rubber type
Lube oil drain hose and drip tray
Oil fill - top and side
Belt guard
Operators' manual and parts list
5-year limited warranty
EPA, CARB & CE compliant
Optional Sound Guard
Generator Dimensions
Length 27.8" (706 mm)
Width 16.3" (414 mm)
Height 20.7" (526 mm)
Weight 356 lbs. (162 kilos)
5.5
BCD
60Hz
5.0
BCD
50Hz
SST
with Sound Guard SST
33.3" (846 mm)
21.1" (536 mm)
22.3" (566 mm)
427 lbs. (194 kilos)
