GE PROFILE PD900DP Dimension Manual

PD900DP
GE Profile 30" Drop-In Electric Range
™
Dimensions and Installation Information (in inches)
Note: Cabinets installed adjacent to slide-in ranges must have an
KW Rating
adhesion spec of at least 194° temperature rating.
240V
11.6
Note: To reduce possibility of scorching the side walls above the
208V
8.7
countertop when no load is present on burners, it is recommended
that a minimum of 6" spacing from adjacent side wall be allowed for
Breaker Size
possible extended, high-heat, element operation.
240V 40 Amps
IMPORTANT: 30" DROP-IN RANGES ARE DESIGNED TO HANG
208V 40 Amps
FROM THE COUNTERTOP. IT DOES NOT REST ON THE FLOOR.
FOR INSTALLATION ALTERNATIVES, REFER TO INSTALLATION
INSTRUCTIONS PACKED WITH PRODUCT.
Optional Kits For Drop-In Electric Ranges (Available At Additional Cost)
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is installed
in 30" free-standing cutout)
JXS32SS (Stainless) - 4" High
JXS32WW (White) - 4" High
JXS32BB (Black) - 4" High
JXS37WW (White) - 5-1/4" High
JXS37CC (Bisque) - 5-1/4" High
JXS37BB (Black) - 5-1/4" High
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
WB07T10681 - White Filler Strip Assembly
WB07T10682 - Bisque Filler Strip Assembly
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center ® service,
800.626.2000.
or
™
30
24
2-7/8"
To Front Surface
of Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
6" Min.
from walls
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
36
support
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
2-7/8"
Specification Created 5/09
To Front Surface
of Countertop
Accessory
Backguard
A/B*
31-1/4
27
26-1/2**
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 29-1/2.
30" Min.
30" Min.
Acceptable Electrical Outlet
23-3/16
Area Also In Adjacent
15" Min.
Cabinet Or Under Floor
Conduit is 40" long
25
27-1/2
7-1/2
30
Listed by
Underwriters
Laboratories
24
31-1/4
220804
Accessory
Backguard
A/B*
