Weider WEEVSY52000 User Manual

Training system

Hide thumbs

Table Of Contents

Quick Links

Enlarged version

ORDERING REPLACEMENT PARTS

If you encounter any difficulties with this product, or if you need to order replacement parts, please call or write

the ICON Health & Fitness, Ltd. office.

ICON Health & Fitness Ltd.

Revie Road Industrial Estate

Revie Road

Leeds

LS11 8JG

Tel: Country Code:

0345-089009

Fax: 0113-2411120

When calling or writing, please provide the following information:

1. The MODEL NUMBER of the product (WEEVSY52000)

2. The NAME of the product (WEIDER

8630 training system)

3. The SERIAL NUMBER of the product (see the front cover of this manual)

4. The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING

attached at the centre of this manual).

Part No. 170831 R0101A

Model No. WEEVSY52000

Serial No.

Write the serial number in the space

above for future reference.

Serial Number Decal (Under Seat)

QUESTIONS?

As a manufacturer, we are com-

mitted to complete customer sat-

isfaction. If you have questions,

or if there are missing parts, we

will guarantee complete satisfac-

tion through direct assistance

from our factory.

Please CALL:

0345-089009

Or WRITE:

ICON Health & Fitness Ltd.

Revie Road Industrial Estate

Revie Road

Leeds

LS11 8JG

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

USER'S MANUAL

Visit our website at

www.weiderfitness.com

Table of Contents

Need help?

Do you have a question about the WEEVSY52000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weider WEEVSY52000

Page 1: Ordering Replacement Parts
Write the serial number in the space above for future reference. Fax: 0113-2411120 When calling or writing, please provide the following information: 1. The MODEL NUMBER of the product (WEEVSY52000) 2. The NAME of the product (WEIDER ® 8630 training system) Serial Number Decal (Under Seat) 3.
Page 2: Table Of Contents
Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the centre of this manual. Remove the PART IDENTIFICATION CHART and the PART LIST/EXPLODED DRAWING before beginning assembly. 4—Weight Stack Weight Stack—5 WEIDER is a registered trademark of ICON Health & Fitness, Inc.
Page 3: Important Precautions
The numbers show the proper route for each Cable. IMPORTANT: If the Cables have not been cor- rectly routed, the WEIDER 8630 will not function properly and damage may occur. 1. It is the responsibility of the owner to ensure 12.
Page 4: Before You Begin
TIGHTENING THE CABLES your body, build dramatic muscle size and strength, or ing. The model number is WEEVSY52000. The serial improve your cardiovascular system, the WEIDER ® number can be found on a decal attached to the train- Woven cable, the type of cable used on the training system, can stretch slightly when it is first used.
Page 5: Assembly
LOCKING THE WEIGHT STACK ASSEMBLY Hole To prevent unauthorised use of the training system, insert a Locking Bar (97) into the indicated hole in Make sure you have the following tools: one of the Weight Guides (23) and secure the Make Assembly Easier for Yourself! Locking Bar with a Lock (27).
Page 6 ATTACHING THE AB STRAP TO THE AB PULLEY Before you begin this step, make sure STATION that you have read all of the information on page 5. This brief introduction will Attach the Ab Strap (35) to the Low Cable (86) at the save you much more time than it takes ab pulley station with a Cable Clip (33).
Page 7: How To Use The Training System
4. Slide the Front Seat Frame (8) onto the indi- HOW TO USE THE TRAINING SYSTEM cated 5/16” x 2 1/2” Carriage Bolts (49) in the Press Base (13). Hand tighten two 5/16” The instructions below describe how each part of the training system can be adjusted. Refer to the exercise Nylon Locknuts (40) onto the Carriage Bolts.
Page 8: Trouble-Shooting And Maintenance
8. Lubricate the insides of the holes in the Top 56. Press two 3/4” Round Inner Caps (78) into Weights (24) as shown. Slide a Top Weight each Pad Tube (28). onto each set of Weight Guides (23). Insert a Pad Tube (28) into the Rear Seat Frame (16).
Page 9 52. Locate and open the parts bag labeled 11. Attach the Leg Press Plate (11) to the “SEAT ASSEMBLY.” Adjustment Tube (10) with a 5/16” x 2 1/4” Bolt (62), two 5/16” Washers (20), and a 5/16” Attach the Small Backrest (18) to the Ab Nylon Locknut (40).
Page 10 15. Attach a Press Arm (7) to one side of the 48. Wrap the Low Cable (86) around a 3 1/2” Press Frame (12) with two 5/16” x 2 1/2” Bolts Pulley (82). Attach the Pulley, a set of Pulley (39) and two 5/16”...
Page 11: Cable Diagrams
44. Route the High Cable (85) around a 3 1/2” 18. Press a 1 3/4” Square Inner Cap (48) into the Pulley (82). Using a 3/8” x 2” Bolt (50) and a lower end of the Left Butterfly Arm (6). Wet 3/8”...
Page 12 21. Wrap the Butterfly Cable (89) around a 3 1/2” 40. Note: The 3 1/2” Pulley (82) used in this Pulley (82) as shown. Attach the Pulley and a step was attached in step 38. It is shown Cable Trap (80) to the bracket on the Leg removed for easier part identification.
Page 13 36. Route the Press Cable (88) over the indicated 25. Identify the Rear Cable (87)—this is the 3 1/2” Pulley (82) attached to the Press shortest Cable. Slide one end of the Rear Frame (12). Be sure that the Cable Trap Cable onto the 5/16”...
Page 14 29. Identify the Press Cable (88)—this is the 32. Route the Press Cable (88) around a 3 1/2” longest Cable. Attach the end of the Press Pulley (82). Attache the Pulley and a set of Cable to the Large “U” Bracket (84) with a Pulley Covers (94) to the lowest set of holes 1/4”...
Page 15 REMOVE THIS PART IDENTIFICATION CHART FROM THE MANUAL 1" x 7/8" Plastic Bushing (54) 1" Inner Cap (95) 1" Round Inner Cap (70) This chart is provided to help you identify the small parts used in assembly. Important: Some parts may have been pre-assembled for shipping purposes.
Page 16 1/4" Washer (37) 1/4" x 2" Machine Screw (63) 5/16" x 1" Bolt (51) Cable Clip (33) 5/16" Washer (20) 1/4" x 2" Carriage Bolt (61) 5/16" x 1 3/4" Bolt (68) 1" Retainer (45) 1/4" x 2 1/2" Machine Screw (64) 3/8"...
Page 17 PART LIST—Model No. WEEVSY52000 R0101A REMOVE THIS PART LIST/EXPLODED Key No. Qty. Description Key No. Qty. Description DRAWING FROM THE MANUAL. SAVE Ab Upright 5/16” x 1” Bolt Top Frame 3/8” x 8” Bolt THE PART LIST/EXPLODED DRAWING Butterfly Frame...
Page 18 EXPLODED DRAWING—Model No. WEEVSY52000 R0101A 40 20 20 40...
