Smartcraft
60
Displays
NMEA2000
Compatible
Gauges
NMEA2000
Compatible
featuring Mercury Gateway
MercMonitor converts engine and system data to
NMEA2000/J1939 protocol for use on NMEA2000/J1939
multifunction gauges and diplays
Merc Monitor Kits
Single Engine- Troll Control- NMEA2000
Single Engine- RPM SmartTow- NMEA2000
Multi Engine- RPM SmartTow- NMEA2000
Multi Engine- GPS SmartTow Pro- NMEA2000
5 Available on Mercury Verado
6 Available on Cummins MerCruiser Diesel Engines
† J1939 limits signals and data levels
MercMonitor
®
®
3 3/8" cutout
Data Level 1
Data Level 2
Data Level 3
Data Level 3
includes GPS antenna
Billet Race Rim
Engines
NMEA2000 Compatible
Outboards & Sterndrives
Systems
Trim Tabs
Depth Sounders
GPS
Chart Plotters
Pucks
Part Number
879337K51
879338K51
879337K52
879339K51
MMRR + color
NMEA2000/J1939†
Out/In Supported Data Level
RPM 1 · 2 · 3
Voltage 1 · 2 · 3
Oil Pressure 1 · 2 · 3
Coolant Temperature 1 · 2 · 3
Tank Level Fuel 1 · 2 · 3
Trim Position 1 · 2 · 3
Water Pressure 1 · 2 · 3
Check Engine Alarm 1 · 2 · 3
Fuel Flow 2 · 3
Engine Hours 2 · 3
5
Boost Pressure 2 · 3
5
Oil Temperature 2 · 3
NMEA2000 Only
Out/In Supported
Data Level
Multiple Tank Levels 2 · 3
Tabs 2 · 3
GPS Speed/COG/
Lat-Lon (in only) 2 · 3
Depth 2 · 3
Sea Water Temp 2 · 3
Paddle speed 2 · 3
Pitot Speed 2 · 3
Rudder Angle 3
6
Gear Pressure 3
6
Gear Temp 3
Fuel Pressure 3
