The GPSMAP 4000/5000 series chartplotter and GPS 17 antenna must be properly installed according to the following instructions. You
need the appropriate fasteners, tools, and mounts listed in each section. These items are available at most marine dealers. Always wear safety
goggles, ear protection, and a dust mask when drilling, cutting, or sanding. When drilling or cutting, always check what is on the opposite side
of the surface. Mount the GPSMAP 4000/5000 series unit in a location that provides a clear, glare-free view of the display and easy operation
of the controls or touch screen. If you experience difficulty installing the unit, seek the assistance of a professional installer; or contact
Garmin Product Support by phone at 913/397.8200 or 800/800.1020, Monday–Friday, 8 AM–5 PM Central Time. Go to
www.garmin.com/support/ and click on Product Support for more information. In Europe, contact Garmin (Europe) Ltd. at
44/0870.8501241.
To install the GPSMAP 4000/5000 series unit:
1. Mount the unit.
2. Mount the antenna.
3. Connect the unit to power and to the antenna.
4. Ensure the unit software is up-to-date.
Though they are not necessary to use the GPSMAP 4000/5000 unit, this manual covers other installation options:
• Connect the unit to other network compatible Garmin devices, such as a sounder or radar.
• Connect the unit to other NMEA 0183 compatible devices such as a VHF radio with DSC.
• Connect the unit to an external alarm.
• Connect the unit to a NMEA 2000 source (available on some boats) for various mechanical and navigation information.
• Connect the unit to a video input source.
• Connect the unit to an external video monitor.
Surface Mounting the GPSMAP 4000/5000 Series Unit
Tools required (not included):
• Drill and drill bit
• Screwdriver
• Pencil
• Mounting hardware (screws or nuts, washers, and bolts)
NoTE: The mounting hardware (screws or nuts, washers, and bolts) are not included. The holes on the bail mount are
Choose mounting hardware that fits the holes in the bail mount and best attaches it to your specific mounting surface. The size of the drill bit
required depends on the mounting hardware chosen.
July 2007
GPSMAP 4000/5000 Series Installation Instructions
4000/5000 S
®
erieS
190-00779-02 Rev. C
i
i
nStAllAtion
nStructionS
/
" (7.9 mm) in diameter.
5
16
Printed in Taiwan
