Foxconn D70S-P User Manual

Foxconn D70S-P User Manual

User manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

D70S Series
Motherboard
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D70S-P and is the answer not in the manual?

Questions and answers

Related Manuals for Foxconn D70S-P

Summary of Contents for Foxconn D70S-P

  • Page 1 D70S Series Motherboard User’s Manual...
  • Page 2 Statement: This manual is the intellectual property of Foxconn, Inc. Although the infor- mation in this manual may be changed or modified at any time, Foxconn does not obligate itself to inform the user of these changes. Trademark: All trademarks are the property of their respective owners. Version: User’s Manual V1.0 for D70S Series motherboard.

  • Page 3: Declaration Of Conformity

    Declaration of conformity HON HAI PRECISION INDUSTRY COMPANY LTD 66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT, TAIPEI HSIEN, TAIWAN, R.O.C. declares that the product D70S Motherboard Series is in conformity with (reference to the specification under which conformity is declared in accordance with 89/336 EEC-EMC Directive) ■ EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio disturbance characteristics of information technology equipment ■ EN 61000-3-2/:2000...
  • Page 4 Declaration of conformity Trade Name: FOXCONN Model Name: D70S Series Responsible Party: PCE Industry Inc. Address: 458 E. Lambert Rd. Fullerton, CA 92835 Telephone: 714-738-8868 Facsimile: 714-738-8838 Equipment Classification: FCC Class B Subassembly Type of Product: Motherboard Manufacturer: HON HAI PRECISION INDUSTRY COMPANY LTD Address: 66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT, TAIPEI HSIEN, TAIWAN, R.O.C.

  • Page 5: Installation Precautions

    Installation Precautions ■ Electrostatic discharge (ESD) is the sudden and momentary electric current that flows between two objects at different electrical potentials. Normally it comes out as a spark which will quickly damage your electronic equipment. Please wear an electrostatic discharge (ESD) wrist strap when handling components such as a motherboard, CPU or memory. ■ Ensure that the DC power supply is turned off before installing or removing CPU, memory, expansion cards or other peripherals. It is recommended to unplug the AC power cord from the power supply outlet.

  • Page 6: Table Of Contents

    TABLe Of CONTeNTS Chapter 1 Product Introduction 1-1 Product Specifications ................2 1-2 Layout ....................4 1-3 Back Panel Connectors ................5 Chapter 2 Hardware Installation 2-1 Install the Memory ..................8 2-2 Install other Internal Connectors ............9 2-3 Jumpers ....................13 Chapter 3 BIOS Setup Enter BIOS Setup ..................16 Main ......................17 F-center ......................19 Smart BIOS .....................19 Fox Intelligent Stepping ................20 CPU Configuration ..................21 Advanced ....................22...
  • Page 7 4-3 FOX LiveUpdate ...................49 1. Local Update ..................49 2. Online Update ..................51 3. Configure ....................54 4. About & Help ..................56 4-4 FOX LOGO ..................57 4-5 FOX DMI ....................58 4-6 Smart charger ..................58...

  • Page 8: Chapter 1 Product Introduction

    Chapter 1 Product Introduction Thank you for buying Foxconn D70S Series mother- board. Foxconn products are engineered to maximize computing power, providing only what you need for break-through performance. This chapter includes the following information: ■ Product Specifications ■ Layout ■ Back Panel Connectors...

  • Page 9: Product Specifications

    PRODUCT INTRODUCTION 1-1 Product Specifications Support Intel® Celeron 847(D70S-V/-VD)&1007u(D70S/-D)&1037u (D70S-P/-PD) Dual-core Processors Max processor power up to 17W For the latest CPU information, please visit: http://www.foxconnsupport.com/cpusupportlist.aspx Chipset Intel NM70 ® Memory 1 x 240-pin SO-DDR3 DIMM Support up to 8GB of system memory Support DDR3 1600(1007u&1037u)/1333MHz architecture...
  • Page 10 PRODUCT INTRODUCTION Back Panel 1 x COM2 port Connectors 1 x HDMI port (D70S/D70S-V/D70S-P) 1 x VGA port 1 x DVI-D port (D70S-D/D70S-VD/D70S-PD) 1 x RJ45 LAN port 3 x Audio ports Hardware Monitor System voltage detection CPU/System temperature detection CPU/System fan speed detection CPU Overheating warning...

  • Page 11: Layout

    PRODUCT INTRODUCTION 1-2 Layout 1. 4-pin ATX 12V Power Connector 10. Front Panel Header 2. System_Fan Header 11. SATA Connectors 3. Front Audio Header 12. 24-pin ATX Power Connector 4. MINI PCI Express Slot 13. INTR Header 5. PCI Express X1 Slot 14. LPT Header 6. Speaker Header 15. DDR3 DIMM Slot 7. ME Header 16. COM1 Header 8. Clear CMOS Header 17. TPM Header 18.

  • Page 12: Back Panel Connectors

    To connect with external display devices, such as monitor or LCD display. 5. DVI-D Port (D70S-D/D70S-VD/D70S-PD) The DVI-D port supports DVI-D specification. Connect a monitor that supports DVI-D connec tion to this port. 5. HDMI Port (D70S/D70S-V/D70S-P) The HDMI (High-Definition Multimedia Interface) provides an all-digital audio/video interface to transmit the uncompressed audio/video signals and is HDCP compliant. Connect the HDMI...
  • Page 13 PRODUCT INTRODUCTION audio/video device to this port. The HDMI Technology can support a maximum resolution of 1920x1080p but the actual resolutions supported depend on the monitor being used. 6.USB 2.0 Ports The USB port supports the USB 2.0/1.1 specification. Use this port for USB devices such as an USB keyboard/mouse, USB printer, USB flash drive and etc. 7. RJ45 LAN Port The Ethernet LAN port provides Internet connection at up to 10/100/1000Mb/s data rate. Left: Active Right: Link Active Link...

  • Page 14: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation This chapter introduces the hardware installation process, including memory, slots, pin headers and the mounting of jumpers. Caution should be exercised dur- ing the installation of these modules. Please refer to the motherboard layout prior to any installation and read the contents in this chapter carefully.

  • Page 15: Install The Memory

    HARDWARE INSTALLATION 2-1 Install the Memory Read the following guidelines before you begin to install the memory : ■ Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage. ■ Memory modules have a foolproof design. A memory module can be installed in only one direction. If you are unable to insert the memory, switch the direction. If you take a look at front side of memory module, it has asymmetric pin counts on both sides separated by a notch in the middle, so it can only fit in one direction. Follow the steps below to correctly install your memory modules into the sockets.

  • Page 16: Install Other Internal Connectors

    HARDWARE INSTALLATION 2-2 Install other Internal Connectors Power Connectors This motherboard uses an ATX power supply. In order not to damage any device, make sure all the devices have been installed properly before applying the power supply. 24-pin ATX power connector : PWR1 PWR1 is the ATX power supply connector.
  • Page 17 HARDWARE INSTALLATION Audio Header : f_AUDIO The audio header supports HD Audio standard. It provides the Front Audio output choice. A_MIC2_L AUD_GND A_MIC2_R PRESENCEJ A_LINE2_R SENSE1_RETURN SENSE_SEND EMPTY A_LINE2_L SENSE2_RETURN F_AUDIO fan Header : SYS_fAN The fan speed can be controlled and monitored in “Health”...
  • Page 18 HARDWARE INSTALLATION front Panel Header : fP1 This motherboard includes one header for connecting the front panel switch and LED Indicators. HDD-LED PWR-LED Hard Disk LeD Connector (HDD-LeD) RESET-SW PWR-SW Connect to the chassis front panel IDE EMPTY indicator LED. It indicates the active status of the hard disks. This 2-pin connector is directional with +/- sign.
  • Page 19 HARDWARE INSTALLATION MINI PCIe Slot : MINI PCIe The MINI PCIE Slot is used to connect MINI PCIE device. Speaker Header : SPeAKeR The speaker header is used to connect speaker of the chassis. EMPTY SPKJ SPEAKER Chassis Intrusion Alarm Header : INTR The header can be connected to a security switch on the chassis.

  • Page 20: Jumpers

    HARDWARE INSTALLATION 2-3 Jumpers For some features needed, users can change the jumper settings on this motherboard to modify them. This section explains how to use the various functions of this motherboard by changing the jumper settings. Users should read the following content carefully prior to modifying any jumper setting.
  • Page 21 HARDWARE INSTALLATION Intel® Me Jumper: PCH_Me_eNABLe This motherboard uses this jumper to enable or disable Intel® Management Engine function. Intel® Management Engine (ME) is an embedded microcontroller located in Intel chipset. It provides latest IT management features such as Intel® AMT, that allows to improve manage- ment of corporate assets.

  • Page 22: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup This chapter tells how to change system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. You have to run the Setup Program when the following cases occur: 1. An error message appears on the screen during the system Power On Self Test (POST) process.

  • Page 23: Enter Bios Setup

    BIOS SETUP enter BIOS Setup The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the message “Press <Del> to enter setup, Press <f7> to enter boot menu” appears at the bottom of the screen, you can press <DEL>...

  • Page 24: Main

    BIOS SETUP Main Main f-center Advanced Boot Power Health Security Save&exit System Date [Sun 02/01/2009] Set the Date. Use Tab System Time [13:31:34] to switch between Date elements. Access Level Administrator Model Name D70S/-P/-V/-PD/-D/-VD ME Version 8.1.30.1350 BIOS Version D32F1D06 Build Date and Time 05/07/2013 17:00:25 Halt On...
  • Page 25 BIOS SETUP [No Errors]: No error can result in system halt. [All, but keyboard]: All errors but keyboard can result in system halt. ► CPU Brand Name It displays the current CPU name. ► Total Memory This item displays the total memory size. The size is depending on how many memory mod- ules are installed in your system before powering on.

  • Page 26: F-Center

    BIOS SETUP f-center Main f-center Advanced Boot Power Health Security Save&exit Super BIOS Protection Super BIOS Protect [Disabled] Settings ▶ Smart BIOS ▶ Fox Intelligent Stepping ▶ CPU Configuration → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt.

  • Page 27: Fox Intelligent Stepping

    BIOS SETUP ► Smart Power LED Smart Power LED is a feature built on your motherboard to indicate different states during Power On Self Test (POST). The LED is located at the front panel, and it displays POST state by different long-short blinking intervals. You can always leave this state enabled. System Status Power LED Status Stop Blinking Condition...

  • Page 28: Cpu Configuration

    BIOS SETUP CPU Configuration Main f-center Advanced Boot Power Health Security Save&exit CPU Configuration Enabled for Windows XP and Linux (OS optimized CPU Brand Name: for Hyper-Threading Intel(R) Celeron(R) CPU 847 @ 1.10GHz CPU Signature 206a7 Technology) and disabled Microcode Patch for other OS (OS not Max CPU Speed 1100 MHZ...

  • Page 29: Advanced

    BIOS SETUP Advanced Main f-center Advanced Boot Power Health Security Save&exit ▶ North Bridge North Bridge Parameters ▶ ME Subsystem ▶ Onboard Device Configuration ▶ SATA Configuration ▶ Super IO Configuration ▶ Trusted Computing ▶ Network Stack → ←: Select Screen ↑...

  • Page 30: Me Subsystem

    BIOS SETUP These items display the memory size installed on each slot. ► Integrated Graphics This item allows you to determine whether to allocate memory for the integrated graphics controller from the system memory. Options: [Auto], [Manual]. [Auto]-Auto the integrated graphics controller. [Manual]- Manual the integrated graphics controller.

  • Page 31: Onboard Device Configuration

    BIOS SETUP Onboard Device Configuration Main f-center Advanced Boot Power Health Security Save&exit Onboard Device Configuration Enabled/Disabled Onboard LAN Controller. Onboard LAN Controller [Enabled] Onboard USB Controller [Enabled] Legacy USB Support [Enabled] Azalia HD Audio controller [Enabled] → ←: Select Screen ↑...

  • Page 32: Sata Configuration

    BIOS SETUP SATA Configuration Main f-center Advanced Boot Power Health Security Save&exit SATA Configuration Enable or disable SATA Device. SATA Controller(s) [Enabled] Onboard SATA Mode [IDE] ▶ SATA Port1: Not Present ▶ SATA Port2: Not Present ▶ SATA Port3: Not Present ▶...

  • Page 33: Super Io Configuration

    BIOS SETUP Super IO Configuration Main f-center Advanced Boot Power Health Security Save&exit Super IO Configuration Set Parameters of Serial Port 1 (COMA) IT8728 Super IO Chip IT8728 ▶ Serial Port 1 Configuration ▶ Serial Port 2 Configuration ▶ Parallel Port Configuration →...

  • Page 34: Trusted Computing

    BIOS SETUP Trusted Computing Main f-center Advanced Boot Power Health Security Save&exit Configuration Enables or Disables Security Device Support [Disable] BIOS support for security device. O.S. will not show Security Current Status Information Device. TCG EFI protocol NO Security Device Found and INT1A interface will not be available.

  • Page 35: Boot

    BIOS SETUP Boot Main f-center Advanced Boot Power Health Security Save&exit Boot Configuration Select the keyboard Bootup Numlock State [On] NumLock state Quiet Boot [Enabled] Fast Boot [Disabled] INT19 Trap Response [Enabled] ▶ CSM parameters Set Boot Priority 1st Boot [Hard Disk] 2nd Boot [CD/DVD]...

  • Page 36: Csm Parameters

    BIOS SETUP CSM parameters Main f-center Advanced Boot Power Health Security Save&exit Launch CSM [Enabled] This option controls if Boot option filter [UEFI and Legacy] CSM will be launched Launch PXE OpROM policy [Do not launch] Launch Storage OpROM policy [Legacy only] Launch Video OpROM policy [Legacy only]...

  • Page 37: Power

    BIOS SETUP Power Main f-center Advanced Boot Power Health Security Save&exit ACPI Sleep State [S3] Select the highest ACPI sleep state the system Resume By PS2 KB/Mouse [Enabled] will enter when the Resume By USB Device(s) [Enabled] SUSPEND button is pressed. Resume By PCIE Device(s) [Disabled] Resume By Onboard LAN...
  • Page 38 BIOS SETUP return to previous state when the STR function wakes. ► Resume By PS2 KB/Mouse This item is used to enable or disable the PS2 keyboard/Mouse to generate a wake up. ► Resume By USB Device(s) This item is used to enable or disable the USB device(s) to generate a wake up. ► Resume By PCIE Device(s) This item is used to enable or disable the PCI Express device to generate a wake up. ► Resume By Onboard LAN This item is used to enable or disable the onboard LAN to generate a wake up.

  • Page 39: Health

    BIOS SETUP Health Main f-center Advanced Boot Power Health Security Save&exit Case Open Warning [Disabled] CPU Warning Temperature CPU Temperature : +84 ˚C System Temperature : +35 ˚C CPU Fan Speed : 6026 RPM System Fan Speed : N/A CPUVcore : +1.008 V VDDR : +1.500V...

  • Page 40: Security

    BIOS SETUP Security Main f-center Advanced Boot Power Health Security Save&exit Set Administrator Security configuration Password. The password must be 1 to 20 characters long. Administrator Password Not Installed User Password Not Installed Administator Password HDD BootSector Write [Normal] ▶ Secure Boot menu HDD Security Configuration: HDD0: HDT722516DLA →...

  • Page 41: Save & Exit

    Discard Changes and Reset saving the changes. Restore Defaults Boot Override Foxconn MS USB2.0 Reade9144 UEFI: Foxconn MS USB2.0 Reade9144 Foxconn CF USB2.0 Reade9144 Foxconn SM USB2.0 Reade9144 Foxconn SD USB2.0 Reade9144 → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt.

  • Page 42: Chapter 4 Cd Instruction

    Chapter 4 CD Instruction The utility CD that comes with the motherboard contains useful software and several utility drivers that enhance the motherboard features. This chapter includes the following information: ■ Install driver and utility ■ FOX ONE ■ FOX LiveUpdate ■ FOX LOGO ■ FOX DMI ■ Smart Charger...

  • Page 43: Install Driver And Utility

    Manual Installation Step by Step Automatic Installation by One Click Drop to System Tray Exit the program Visit Foxconn's Show Utilities Show Drivers Browse CD View User’s Manual website Choose the items you want to Install...

  • Page 44: Install Utility

    CD INSTRUCTION 2. Install Utility Use these options to install additional software programs. And click “User’s Manual“ button to view the product manual. The Driver and Utility items displayed above represent a Windows 7 based system. The appearance may change with different Operating Systems.

  • Page 45: Fox One

    CD INSTRUCTION 4-2 fOX ONe FOX ONE is a powerful utility for easily modifying system settings. It also allows users to monitor various temperature values, voltage values, frequencies and fan speeds at any time. With FOX ONE, you can : ■ Monitor hardware temperatures, voltages, frequencies and fan speeds.

  • Page 46: Main Page

    CD INSTRUCTION 1. Main Page Show CPU Information Toolbar Alert Lamp Switch Button Skin Button Exit Minimum Configuration Homepage Monitor Frequency/Voltage/Fan speed/Temperature value Toolbar Use the toolbar to navigate to other pages. Alert Lamp When the system is in healthy state, the color of alert lamp is green. When the system is in abnormal state, the alert lamp color is red.
  • Page 47 Minimum Click this button to drop the FOX ONE to Windows system tray located at the lower right corner of your screen. Homepage Click this button to visit Foxconn motherboard website : http://www.foxconnchannel.com Configuration 1). Monitor interval (ms) : This is to define the interval of different messages of system settings which are to be displayed...
  • Page 48 CD INSTRUCTION 2). Simple Mode : To select which message of system settings are to be displayed in the Simple Mode. Messages such as CPU frequency, voltage...etc., they can be displayed one by one in Simple Mode. 3). F.I.S. Calibration (FOX Intelligent Stepping, Optional): This function will re-calibrate the CPU's loading, and it may take several minutes to proceed.

  • Page 49: Cpu Page - Cpu Control

    CD INSTRUCTION 2. CPU Page - CPU Control This page lets you select (or overclock) CPU clock to meet the current performance level of the system. The fastest and suitable CPU clock running for current system can be calculated by FOX ONE automatically or manually input by yourselves.
  • Page 50 CD INSTRUCTION A message informs you to push RESET button later if the system hangs finally. Click Yes to continue. You can see the system is raising CPU clock until the system hangs. Push RESET button on the front panel of your system to restart the computer.
  • Page 51 CD INSTRUCTION Now, your system is running at a CPU clock of 255MHz. fOX Intelligent Stepping (f.I.S., Optional) Select FOX Intelligent Stepping will allow your system to automatically adjust your CPU clock rate based on different system loadings. For example, if you select Power Gaming, CPU clock will be driven to run at its maximum speed.

  • Page 52: Frequency Page - Frequency Control (Optional)

    CD INSTRUCTION 3. frequency Page - frequency Control (Optional) This page lets you set memory and PCI Express frequencies by manual. Go to Freq. page Close this page Select the option you want to set Adjust by manual Reset the changes Apply the changes 4.
  • Page 53 CD INSTRUCTION 4.2 Limit Setting - System Temperature This page lets you to set system high limit temperature and enable the alert function. Show current system temperature value Enable alert function when the system temperature is higher than high limit value Show current high limit value of system temperature Set high limit by dragging the lever...
  • Page 54 CD INSTRUCTION 4.4 Limit Setting - System Fan This page lets you to set system fan low limit rpm and enable the alert function. Show current system fan rpm value Enable alert function when the system fan runs slower than low limit rpm value Show current low limit rpm value of system Set low limit rpm by dragging the lever...

  • Page 55: Voltage Page - Voltage Control (Optional)

    CD INSTRUCTION 5. Voltage Page - Voltage Control (Optional) This page lets you set CPU voltage, memory voltage and North Bridge voltage manually. CPU voltage can be stepped up/down by a unit of 12.5mV, while memory is 0.05V/step, and North Bridge is 0.04V/step. Go to Voltage page Select the option you want to set Adjust by manual Reset the changes Apply the changes 6.

  • Page 56: Fox Liveupdate

    CD INSTRUCTION 4-3 fOX LiveUpdate FOX LiveUpdate is a useful utility to backup and update your system BIOS, drivers and utilities by local or online. Supporting Operating Systems : ■ Windows 7 (32-bit and 64-bit) ■ Windows 8 (32-bit and 64-bit) Please set the BIOS setting “BIOS Write Protect” or “Super BIOS Protect” to [Disabled] when running this application.
  • Page 57 CD INSTRUCTION Key in a BIOS name Click here 1-3 Local Update - Update This page helps you to update your BIOS from a local file. After click “Update”, An alert message will be displayed to ensure if you really want to continue, click “Yes” to confirm. A setup wizard will guide you to load a local BIOS file to finish the operation. You must remember from which directory to load your new BIOS file (with an extension of ".BIN" for Award BIOS, ".ROM" for AMI BIOS) before the setup wizard starts. FOX LiveUpdate can automatically backup old BIOS before update. This feature can be enabled in the "Configure-System" setup. Please refer to "Configure- System" section for more detail. The default backup directory is C:\LiveUpdate_ Temp, but the backup file name will be automatically generated. It is hard to find it out from a backup directory, and we recommend you using Explorer to check date/ time message of this backup file to find it out and write its name down to remember...

  • Page 58: Online Update

    CD INSTRUCTION 2. Online Update 2-1 Online Update - Update BIOS This page lets you update your system BIOS from Internet. Click “Start”, it will search the new BIOS from Internet. Then follow the wizard to finish the update operation. Click here Current information Search new BIOS from Internet Select BIOS to update Browse detailed information Update BIOS Close the window 2-2 Online Update - Update Driver...
  • Page 59 CD INSTRUCTION Select the driver to update Browse detailed information Install the selected driver Close the window 2-3 Online Update - Update Utility This page lets you update utilities from Internet. Click “Start”, it will search the new utilities from Internet. Then follow the wizard to finish the update operation. Click here Current information Search new utilities from Internet Select the utility to update...
  • Page 60 CD INSTRUCTION 2-4 Online Update - Update All This page lets you update your system drivers from Internet. Click “Start”, it will search all new BIOS/drivers/utilities from Internet. Then follow the wizard to finish the update operation. Click here Current information Search all new BIOS/ drivers/utilities from Internet Browse detailed BIOS information Browse detailed driver information Browse detailed utility information Close the window...

  • Page 61: Configure

    CD INSTRUCTION 3. Configure 3-1 Configure - option This page lets you set auto search options. After you enable the auto search function, FOX LiveUpdate will start its searching from Internet and if any qualified item found, it will pop out a message on the task bar to inform you to do the next step. Click here Set auto search options Set auto search the latest FOX LiveUpdate...
  • Page 62 CD INSTRUCTION When you enable "Auto Search FOX LiveUpdate", if your FOX LiveUpdate version is older, it will auto search from internet and prompt you to install the new version. Prompt you to install the new FOX LiveUpdate 3-2 Configure - System This page lets you set the backup BIOS location and determine if the FOX LiveUpdate can auto run when the system starts up.

  • Page 63: About & Help

    CD INSTRUCTION 3-3 Configure - Advance This page lets you select to flash BIOS / Boot Block. If you choose Flash Boot Block, it means BIOS is not protective, and you must make sure the flash process is continuous and without any interruption. Click here Select which BIOS ROM to flash(Only available to motherboard with backup BIOS ROM ) Select to flash Boot Block Apply the changes Reset to default value We recommend that you had better keep the default setting unchanged to avoid any damage.

  • Page 64: Fox Logo

    CD INSTRUCTION 4-4 fOX LOGO FOX LOGO is a simple and useful utility to backup, change and delete the boot time Logo. The boot Logo is the image that appears on screen during POST (Power-On Self-Test). You can prepare a JPG image (1024x768) file, then use FOX LOGO to open it and change the boot time Logo. Boot time Logo will be displayed if you enable the BIOS "Quiet Boot" setting in "Advanced BIOS Features" menu. Supporting Operating Systems : ■ Windows 7 (32-bit and 64-bit) ■ Windows 8 (32-bit and 64-bit) Main screen...

  • Page 65: Fox Dmi

    CD INSTRUCTION 4-5 fOX DMI FOX DMI is a full Desktop Management Interface viewer, and it provides three DMI data formats: Report, Data Fields and Memory Dump. With DMI information, system maker can easily analyze and troubleshoot your motherboard if there is any problem occurred.
