2-7 onboard Button

Power on Button: PoWeR_oN
Push the power on button to power on the system.
Reset Button: ReseT
Push the reset button to reboot the system.
force Reset Button: foRCe_ReseT
Simply rebooting after applying new OC settings can cause the system to fail because the hardware
has not been reset properly. But with one press of the Force Reset button, your system will not only
re-boot, but also re-tune itself! This button triggers the CPU, memory controller and chipset to re-
initialize, running hardware checks and timing algorithms before reloading with your new overclocking
settings. This reduces instances of failed re-boots after implementing OC settings.
FORCE_RESET
POWER_ON RESET

2-8 onboard leD

DRAM Power leD:
The LED lights up indicating the system is on or the
system is staying at S1 or S3 sleeping state.
+5V standby leD:
It will light whenever the power supply that connected to
the motherboard is switched on.
DIMM3 sPD Detect leD:
The Normal status is on. When the DDR in DIMM3 is not
support SPD address in DIMM3, the LED will turn off.
Do not remove or plug in any device when the onboard LED is lighting on.
