- Page 1 WIRELESS DIGITAL SECURITY CAMERA USER’S GUIDE English Version 1.0 www.lorextechnology.com LW2175R SERIES...
- Page 2 Thank you for purchasing this Lorex product. This manual refers to the following products: • LW2175R • LW2175RPK2B Please visit us on the web for the most current Manuals and Quick Start Guides. Additional Language Manuals may also be available at: www.lorextechnology.com...
-
Page 3: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. - Page 4 Service 13. Servicing - Do not attempt to service this video 19. Cleaning - Unplug the video product from the wall equipment yourself as opening or removing covers outlet before cleaning. Do not use liquid cleaners or may expose you to dangerous voltage or other aerosol cleaners.
-
Page 5: General Precautions
General Precautions 1. All warnings and instructions in this manual should be followed. 2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use a water dampened cloth for cleaning. 3. Do not use the receiver in a humid or wet place. 4. -
Page 6: Camera Features
Features • FHSS Digital Wireless Technology provides excellent image quality and clarity • Simple installation. No video cable required (1) • Connect multiple receivers to your surveillance recorder (DVR) to create a wireless surveillance solution (2) • Easily connects to a TV/Monitor (RCA) or DVR (BNC) •... -
Page 7: Table Of Contents
Table of Contents Getting Started ..........1 Wireless Receiver &... - Page 8 viii...
-
Page 9: Getting Started
Getting Started The system comes with the following components: 1 X WIRELESS CAMERA* 1 X CAMERA MOUNTING STAND 1 X WIRELESS RECEIVER* 1 X MOUNTING SCREW KIT 1 X BNC/RCA ADAPTER 2 X POWER ADAPTERS* (FOR RECEIVER & CAMERA) 3FT/1M BNC FEMALE/BNC MALE 1 X POWER SPLITTER CABLE FOR RECEIVER EXTENSION CABLE (Included with 2 pack only) -
Page 10: Wireless Receiver & Camera
Wireless Receiver & Camera 2 3 4 Wireless Antenna Resolution button: Press to switch between VGA* and QVGA video resolutions. Front LED: Glows green to indicate receiver is powered up. Pairing Button: For details, see “Pairing Cameras” on page 8. BNC Connector: Connect the BNC connector to the DVR or BNC extension cable. -
Page 11: Connecting The Camera
Connecting The Camera Connecting The Camera • Before you install the camera, carefully plan where and how it will be positioned, and where you will route the cable that connects the camera to the power adapter. • Before starting permanent installation, verify its performance by observing the image on a monitor when camera is positioned in the same location/position where it will be permanently installed. - Page 12 Connecting The Camera Twist the camera into the head of the stand (1). Adjust the angle of the camera until the desired view is set. Tighten the thumbscrews to secure the desired camera position (2). Connect the power cable from the camera to the Power Adapter. Plug the power adapter to an outlet or surge protector.
-
Page 13: Wireless Receiver Setup
Connecting The Camera Wireless Receiver Setup To connect a wireless receiver to a surveillance recorder (DVR): Connect the BNC connector on the receiver directly into an available video input. Make sure to first connect and power on the camera(s) before powering on the receiver;... -
Page 14: Installing Multiple Wireless Cameras
Connecting The Camera Installing Multiple Wireless Cameras When installing multiple digital wireless security cameras in the same environment maintain as much space as possible between the receivers using the included 3ft BNC extension cables, to optimize camera performance. See illustrations below for examples of recommended 2 and 4 receiver installations. -
Page 15: On-Screen Display
Connecting The Camera On-Screen Display Status Indicator Signal Indicator Signal Indicator:The signal indicator shows the strength of the signal being received from the camera. The number of bars in the signal indicator shows the strength of the signal. One or no bars indicates the signal is poor. Four bars indicate a very strong signal. Status Indicator: The status indicator message "Connecting"... -
Page 16: Pairing Cameras
Connecting The Camera Pairing Cameras IMPORTANT The camera and receiver have already been pre-paired at the factory, which means that they are exclusively communicating with each other. If for some reason the pairing is lost, follow these steps to pair up the camera and receiver. To pair the camera to the receiver: Make sure that the camera and receiver are both powered up. -
Page 17: Appendix A: System Specifications
Appendix A: System Specifications Appendix A: System Specifications Receiver Receiving Frequency Range 2.400GHz~2.480GHz RX Sensitivity -81dBm Demodulation GFSK Data Rate 160 Kb/s Supported Resolutions VGA (640x480) up to 12 FPS or QVGA (320x240) up to 25 FPS Power Requirement 12Vdc +/-10% Power Consumption 200mA Max Operating Temp Range... -
Page 18: Appendix B: About Digital Wireless Technology
Appendix B: About Digital Wireless Technology Appendix B: About Digital Wireless Technology The Digital Wireless signal transmission type used by the Lorex LW2175R is also known as FHSS -Frequency Hopping Spread Spectrum. This type of signal results in a private, interference-free signal. -
Page 19: Appendix C: Facts About Digital Wireless Cameras
Appendix C: Facts About Digital Wireless Cameras Appendix C: Facts About Digital Wireless Cameras Wired VS Wireless Cameras A wired camera has a video cable that transmits the video signal from the camera to a recording or viewing device. A wireless camera does not use a video cable. Instead, it wirelessly transmits the video signal to a wireless receiver that is connected to your recording or viewing device. - Page 20 How many frames per second should I expect from a digital wireless camera? Current Lorex digital wireless cameras offer 10 - 30 FPS (Frames Per Second) performance. Actual frame rate depends mainly on signal strength and resolution (see the chart above).
-
Page 21: Appendix D: Troubleshooting
Appendix D: Troubleshooting Appendix D: Troubleshooting If you have problems with your System, there is often a quick and simple solution. Please try the following: Problem Solution There is no picture from a • Check power to the camera. Make sure the adapter camera is plugged in properly. -
Page 22: Appendix E: Frequently Asked Questions
Appendix E: Frequently Asked Questions Appendix E: Frequently Asked Questions Q: What is the maximum distance I can have between the camera and the receiver? A: Typically 450 feet (137 m) with a clear line of sight in open space, or approximately 150 feet (46 m) in a house. -
Page 23: Appendix F: Extending Wireless Range
Appendix F: Extending Wireless Range Appendix F: Extending Wireless Range The receiver included with the LW2175R series does not support range extender antennas. Should you require a wireless range extension, a range extender accessory kit is available. Wireless range extension should be considered if you experience a low signal strength ... - Page 24 LW2175R SERIES Ver sion 1.0 www.lorextechnology.com Copyright © 2011 Lorex Technology Inc.
