- Page 1 SUPERTHIN LaRgE TILT MOUNT ™ SECURE, EASY TO INSTALL, LOW PROFILE TILTINg MOUNT INSTaLLaTION MaNUaL aNd waRRaNTy " " lbs. (106-160cm) (54.43kg)
-
Page 2: Safety Warning
Improper installation can cause damage or serious please call a qualified contractor or contact Monster injury. Do not use this product for any purpose not Cable Products, Inc. - Page 3 4.92" to 33.46" (12.5cm to 85cm) 34.78" (88.6cm) Specifications and Notes VESA 200×200 / 300×300 / 400×200 / 400×400 / 600×400 / 800×400 Compliant ™ Monster is constantly striving to improve its products. Specifications are subject to change without notice.
-
Page 4: Package Contents
4 each M6×10 / M6×15 / M6×25 4 each M8×10 / M8×15 / M8×25 1 Electronic 1 Bubble Level Studfinder Package Contents If any parts are missing, please call the appropriate Monster number for your location. See page 2 for phone numbers. -
Page 5: Read Before Installing
(5) DO NOT install in a location where there is anchors) are included, masonry mounting requires excessive dust, smoke or moisture. These sources specialized knowledge, skills and tools. Monster can create a fire. highly recommends that you seek the assistance of a professional installer when mounting to masonry. -
Page 6: Required Tools
Above tools from any source of heat or water. Replace ³ ∕ ₁₆ " drill bit with ½" masonry drill bit Hammer TIP: To hide your TV’s power cord and AV cables, install a Monster FlatScreen CleanView Cable ™ ™... - Page 7 Installing the wall Mounting Plate Remove all pieces of the wall mounting system to ensure you have all necessary parts. wood Stud Mounting An electronic studfinder is included. Remove plastic tab on the back of the studfinder to activate battery. To locate a wall stud, hold the studfinder against the wall where you want to mount your TV.
- Page 8 wood Stud Mounting (cont’d) With your electric drill and ³ ∕ ₁₆ " bit, pre-drill a 3" deep hole where indicated on template. After drilling holes, remove template from wall. Position the wall mounting plate over the holes drilled in the wall studs. Make sure the wall plate is level by using the supplied bubble level.
- Page 9 wood Stud Mounting (cont’d) With the help of another person, attach the wall plate to the wall using the lag bolts and round washers as shown to the right. Tighten each bolt with your wrench. Turn clockwise until secure. Continue to page 13 to continue your installation. DO NOT over tighten bolts.
- Page 10 Masonry Mounting Masonry mounting requires specialized knowledge, skills and tools. Monster highly recommends that DO NOT drill holes in masonry you seek the help of a professional installer when mortar joints. mounting to masonry. Position the supplied cardboard template in the desired location and tape template to wall with masking tape.
- Page 11 Masonry Mounting (cont’d) Install the supplied plastic concrete anchors in each hole. Tap into hole with hammer until fully seated. Position the wall mounting plate over the holes drilled in the wall studs. Make sure the wall plate is level by using the supplied bubble level.
- Page 12 Masonry Mounting (cont’d) With the help of another person, attach the wall plate to the wall using the lag bolts and round washers as shown to the right. Tighten each bolt with your wrench. Turn clockwise until secure. DO NOT over tighten bolts. This can DO NOT release the wall plate until damage the wall plate or the surface of you are absolutely sure it is secured to...
- Page 13 attaching your Flatscreen TV to the Tilting Vertical adjustment Bars DO NOT lay your TV face down when attaching the TV mounting plate. This The television should be unplugged can cause permanent damage to your before threading any bolt or screw into screen.
- Page 14 Hanging your Flatscreen TV and Tilting Vertical adjustment Bars on the wall Plate Connect the TV’s power cord and any AV cables to the TV before hanging it. Plug the TV’s power cord into a nearby AC outlet. If routing AV cable in wall, run it through the prepared opening in your wall.
- Page 15 adjusting Tilt angle of TV The tilt angle can be adjusted up to 12°. To tilt down, gently pull the upper part of your TV away from the wall. At first you’ll hear a click, then you will be able to tilt to the maximum angle. To tilt up, gently push back to make the TV parallel to the wall.
- Page 16 Congratulations You’ve successfully installed your Monster SuperThin FlatScreen Mount. ™ Visit us at www.MonsterCable.com/FlatScreen for more innovative Monster FlatScreen products. Removing your Flatscreen TV from the wall Plate Note: A cord is attached to the bottom of each vertical adjustment bar. If it is necessary to remove the TV for any reason, pull the cords on both bars to release locking mechanism.
- Page 17 Ultra-soft for easy routing and installation. Exclusive Monster MicroFiber cloth won’t scratch delicate screen patented technologies deliver the advanced coatings. performance you need from your flatscreen TV. For more details on all our Monster FlatScreen products, visit us at MonsterCable.com/FlatScreen...
-
Page 18: Limited Warranty For Consumers
(including without transferred ownership of the Product, whichever occurs limitation building and/or electrical codes), (iv) in earlier. Also, You must call Monster and obtain a Return accordance with manufacturer recommendations and / Authorization Number (as described under “How to or instructions in the materials and documentation that Make a Claim”) within two (2) months after You discover... - Page 19 English and other versions of this Limited Warranty, the instructed on how to properly submit the estimate and English version shall prevail. the resulting invoice to Monster for payment. Any fees for repairs may be negotiated by Monster. REGISTRATION. Please register Your Product at www.monstercable.com.
