The interface connectors are located on the rear of the printer.
SERIAL
INTERFACE
LAN
PARALLEL
PARALLEL
USB
INTERFACE
INTERFACE
INTERFACE
INTERFACE
Insert the parallel interface cable into the parallel connector and fasten it by means of the clips.
Insert the serial interface cable into the serial connector and fasten it by means of the two screws (use
the screwdriver).
Insert the USB interface cable into the USB connector
Insert the LAN interface cable into the LAN connector.
13
