Unpacking
Your Voodoo Lab Pedal Power box should contain the following:
Pedal Power 2 Plus system unit
Warranty card
AC power cord
DC Power cables:
5.5x2.1mm right angle barrel connectors (6)
5.5x2.1mm straight barrel connectors (2)
5.5x2.5mm "red" barrel (1)
3.5mm mini plug (1)
9V battery snap (1)
Please take a moment to fill out and mail your warranty card. This
will register your warranty, make you eligible for technical support,
and allow us to notify you with updates and new product information.
Don't worry, we respect your privacy and never sell our mailing list.
System Unit Description
1.
AC auxiliary. This is a courtesy AC outlet for convenient
powering of AC powered effects or a MIDI foot controller.
Note the 200 watt maximum rating. Do NOT plug in your
amp here!
2.
AC power input jack. This is a standard "IEC-type" connector.
