PEDAL POWER
AC
User's Manual
Copyright 2005-2008 by Digital Music Corporation.
This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted
by any means or in any form without the express prior consent in writing from Digital Music Corporation.
Voodoo Lab and Pedal Power are trademarks of Digital Music Corp.
Advertisement
Table of Contents
Related Manuals for Voodoo Lab Pedal Power AC
Summary of Contents for Voodoo Lab Pedal Power AC
- Page 1 This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted by any means or in any form without the express prior consent in writing from Digital Music Corporation. Voodoo Lab and Pedal Power are trademarks of Digital Music Corp.
- Page 3 User’s Manual Introduction The Voodoo Lab Pedal Power AC is the finest power supply available for AC powered guitar effects and accessories. It’s the only professional solution for powering vacuum tube overdrives and effects, MIDI footcontrollers, and high current digital processors--without cumbersome and noise inducing wall warts.
- Page 4 1. AC mains auxiliary. Note the 200 watt maximum rating. 2. AC mains power input jack. This is a standard “IEC-type” connector. 3. Power indicator. This LED indicates the Pedal Power AC system unit is operating. 4. 9VAC output jacks (2). Each output provides up to 600mA.
- Page 5 Connections The Voodoo Lab Pedal Power AC has four outputs and six output jacks. These accept barrel type connectors and have a 2.5mm center pin. The two individual 9VAC outputs on the left will provide up to 600mA each. The two pairs of jacks on the right will provide up to 1200mA each at either 9VAC or 12VAC.
- Page 6 Protection Your Pedal Power AC is designed to be fault tolerant. This means that if you try to power a defective device or use a bad cable, it will simply turn off that output until the problem is corrected. Similarly, if you try to power something that requires more current than the Pedal Power AC can provide, it switches off only that output.
- Page 7 Specifications Input: IEC connector Check label on base for input power: • 100V 60Hz (Japan) • 120V 60Hz (North America) • 230V 50/60Hz (Europe/Australia) Outputs: 5.5x2.5mm barrel connectors Two 9VAC at 600mA Two selectable 9/12VAC at 1200mA Short circuit and overcurrent protected. Physical: 6”...
- Page 8 If the product should become defective within the warranty period, Voodoo Lab will repair it or replace it free of charge, provided it is returned freight prepaid to Voodoo Lab with a valid RMA (return material authorization) number.
