Summary of Contents for Voodoo Lab PEDAL POWER 4x4
- Page 1 PEDAL POWER 4x4 User’s Manual www.voodoolab.com...
- Page 2 Copyright ©2009-2012 by Digital Music Corporation. This publication is protected by copyright and all rights are reserved. Voodoo Lab and Pedal Power are trademarks of Digital Music Corp. rev 1.0...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Unpacking Connections DC Power Cables Strymon Boss Pedals Line 6 Modeling Pedals TC Electronic Eventide . Additional Cables About Isolation Specifications . Warranty . How to Reach Us... -
Page 4: Introduction
Introduction Pedal Power 4x4 is a high-current capable power supply for pedal effects and accessories. With eight independent, filtered and regulated output sections, Pedal Power 4x4 can properly power modern DSP-based effects and all 9V battery operated pedals. Nearly all DSP-based effects made today are supplied with digital switching power adapters, which produce significant high frequency noise. -
Page 5: Unpacking
Unpacking Your Voodoo Lab Pedal Power 4x4 box should contain the following: Pedal Power 4x4 unit Warranty card AC line cord DC Power cables: 5.5x2.1mm right angle barrel connectors (6) 5.5x2.1mm straight barrel connectors (2) 5.5x2.5mm right angle “red” barrel (1) 3.5mm right angle mini plug (1) -
Page 6: Connections
Connections Pedal Power 4x4 is powered directly from mains using the supplied AC line cord. This is a standard computer-type IEC line cord, so it’s easy to obtain a replacement or different length. Important: Pedal Power 4x4 is manufactured to operate from a specific supply voltage (100V, 120V or 240V) which is marked on the bottom of the unit. -
Page 7: Dc Power Cables
“center positive” are the Fulltone ‘69, SoulBender, and Octafuzz pedals and Moogerfoogers. Reverse polarity cables are available from Voodoo Lab to properly power these pedals. Strymon All Strymon pedals (including the larger format Timeline) can be powered from any of the high-current 9V outputs using a standard black 5.5x2.1mm barrel... -
Page 8: Line 6 Modeling Pedals
5.5x2.5mm barrel cable. This does not match the rating of the supplied Line 6 adapter, but does correctly power these pedals. Note that PODxt & HD, M9, M13 and the JM4 Looper cannot be powered by Pedal Power 4x4. TC Electronic TC Electronic’s Nova pedals such as the Delay, Modulator and Reverb are... -
Page 9: Additional Cables
Additional Cables The DC power cables supplied with your Pedal Power 4x4 are suitable for most common pedal effects. If you need additional cables, different lengths, reversed polarity, or a special connector, these are available from Voodoo Lab at our online store. -
Page 10: About Isolation
The isolated outputs of Pedal Power 4x4 eliminate this noise. Another benefit of isolation is that you can power both negative ground and positive ground effects with Pedal Power 4x4. Negative ground effects are by far the most common, however the Fuzz Face and Octavia are some well known examples of positive ground circuits. -
Page 11: Specifications
Specifications Input: Standard IEC connector 120V 50/60Hz (North America model) 100V 60Hz (Japan model) 220-240V 50/60Hz (Europe/Australia model) Model and input power are marked on bottom of unit. Outputs: 5.5x2.1mm barrel connectors center negative Short circuit protected. Two 9V or 12VDC - 400mA Two 9VDC - 400mA Four 9VDC - 100mA Physical:... -
Page 12: Warranty
Should you experience any difficulty with this Voodoo Lab product, contact us as described below. If it is determined that the product must be returned to the factory for repair, you will be issued an RMA and given shipping and packaging instructions.
