Operating the Cash Drawer

Connecting and Locking the Cash Drawer

1.
Place the cash drawer on a flat surface near your POS work center.
2.
Connect the interface cable:
a.
Connect the POS printer interface cable to the MultiPRO® interface underneath or on the
rear of the cash drawer, then connect the other end of the cable to the printer.
NOTE:
HP POS printers. If you are connecting the cash drawer to a printer other than HP POS
printers, select the appropriate interface cable for your printer model.
WARNING!
volt may result in unpredictable performance, such as the cash drawer not opening or
opening unexpectedly, in addition to the possible damage to the cash drawer and printer.
OR
b.
For the USB cash drawer model, connect one end of the provided USB interface cable to
the USB connector underneath the cash drawer and the other end of the cable to the host
computer or to a powered USB hub connected to the host computer.
3.
Assemble and install the inner drawer divider kit using the installation steps provided in the kit.
4.
Use the security key supplied with the cash drawer to turn the lock to the online position. Refer
to the following illustrations for other lock positions for your model.
NOTE:
lock and key system in accordance with your company's security policy. HP is not responsible
for the security of the cash drawer, damage to the cash drawer, or the replacement of lost keys.
Figure 2-1
Table 2-1
Select This Lock Option
1
The printer interface cable provided with the cash drawer is designed to work with
HP Cash Drawers only support 24 volt. Connecting an HP Cash Drawer to 12
Before using the cash drawer, it is recommended that you create a unique and secure
Lock Options (Heavy Duty Cash Drawer)
Lock Options (Heavy Duty Cash Drawer)
Locked Closed
To Do This
Prevents the cash drawer from being opened by an electrical signal
from the printer. Use this security method when it is necessary to be
away from the drawer for only a short period.
Connecting and Locking the Cash Drawer
