Velodyne SC-600 IW Specifications

SC-BOO
Series
SC-600 IW [In-Walll Subwoofer
The SC-600 IW is an affordable in-wall subwoofer that fits flush in a standard 2x4
studded wall yet delivers high output, dynamic bass for music and home theater. The
unique four driver design, driven
by
a perfectly matched 400 watt dynamic power,
200
watt
RMS amplifier, reproduces the most demanding home theater, musical or
gaming material with incredible authority, accuracy and low distortion.
Features
• Fits FLUSH in a standard 2x4 studded wall
• Easy to install for new construction or retrofit
• Amazingly deep, powerful bass performance with minimum wall vibration
• Full feature IR remote control with presets for four different listening preferences,
volume control. phase adjustment and night mode
• Connects with conventional speaker wire
• Comes complete with a compact 1S.25" x 14" grille
• The matched SC-SOO amp incorporates exclusive Velodyne digital
distortion-limiting software, superior headroom, and an automatic
7 -band room EQ complete with mic
Four Driver Configuration
The SC-SOO IW incorporates two active long throw, S.5" drivers with 2" two layer
voice coils and two 14" x 3.5" passive radiators in a counterbalanced design that limits
wall vibration. This unique approach creates as much bass radiating surface as a
14.5" driver, but fits easily in a 2" x 4" wall with a small 1S.5" x 14.25" footprint.
Easy to Install Design
Preliminary
The SC-SOO IW features a unique mounting system that accomodates both new construction and retrofit situations.
The sealed cabinet attaches to standard 2x4 studs using six drywall screws, three on each side, while the top and
bottom of the enclosure are secured to the drywall using four clamps. The perforated, paintable metal grill presses
tightly into the cabinet to form a small, low silhouette that virtually disappears into the wall.
Easy to Configure
The SC-SOO IW is driven by the SC-SOO rack-mountable amplifier that features 400 watts dynamic power and 200
watts of continuous RMS power. The SC-SOO is precisely tuned with DSP control. and has a built-in test tone
generator, 7 -band automatic room equalizer, microphone, 12-volt trigger, IR repeater jack, RS-232 control port
(Crestron Certified). and comes with a full feature remote control with four listening presets. The crossover and
volume controls, and mic jack for room bass EQ are on the front panel making setup a breeze.
www.vslodyns.com
