Summary of Contents for Velodyne SubContractor Series SC-1250

  • Page 3 • A reference sub for every installation situation – Cabinet, wall, floor, ceiling, free standing • SPL-R performance • Outboard amplifier – Runs up to two subs • Standard speaker wire connections What is the SC Series?
  • Page 4 SC-1250 Amplifier • 1250 watts RMS, 3000 watts peak • 7-band Auto-EQ (mic included) • DSP control • Rack mount ears included • Remote with presets, phase, etc. MIC INPUT VOLUME CONTROL LED – Volume, CROSSOVER Crossover, CONTROL Model Select IR INPUT...
  • Page 5 SC-1250 Amplifier - continued • Easy Hookup and Setup RS-232 CONTROL RCA, BALANCED, (CRESTRON SPEAKER CERTIFIED) LEVEL INPUTS CONTROL FOR UP MIC INPUT TO 2 SC SUBS TRIGGER (PROTECTED) IR REPEATER...
  • Page 6 – SC-12: 14 3/4” x 14 3/8” x 10 1/8” – SC-15: 18 3/8” x 18” x 13 3/8” • Connects with conventional speaker wire • Down-firing or front-firing • Fits easily into standard millwork • Line drawings posted on www.velodyne.com SubContractor Subwoofers...
  • Page 7 SC-IF (In-Floor) / SC-IC (In-Ceiling) • Dimensions (HWD): – SC-IF / SC-IC: 25 3/4” x 14” x 9” • Fits between joists • Multiple applications • Out performs the SPL-1200R • 4 mounting brackets included • Internal bracing...
  • Page 8 SC-IW In-Wall Subwoofer DRIVER DRIVER MODULE (Fires up or down) (Thermally protected) ¼” Thick aluminum sandwich CABINET MODULE (Pre-Installed) DESIGNER GRILL STANDARD GRILL (18” x 4.64”) (17” x 13.8”)
  • Page 9 SC-IW In-Wall Driver • Vertically firing T-shaped driver • Maximizes driver travel / output • Minimizes wall vibration • Propriety Patent Pending Driver Design • Unique “drive shaft” design • Neodymium motor structure...
  • Page 10 Velodyne SubContractor Series Subwoofers Room Sizing Chart SC-15 SC-IF/IC SC-12 SC-IW SC-10 SC-8 1000 2000 Note: Calibrated for High-Output Bass Performance Spec Enough Sub(s)! 3000 4000 Room Size in Cubic Feet 1 Subwoofer 2 Subwoofers 3 Subwoofers 4 Subwoofers 5000...
  • Page 11 A Sub For Every CI Need! SC Series = Always having a sub for any installation...
  • Page 12 SC Series In-Wall Subwoofer Close-Up on the SC-IW (In-Wall)
  • Page 13 In-Wall Driver The Driver...
  • Page 14 Complete In-Wall Assembly With Standard Grill With Designer Grill Enclosure Enclosure Module Module Driver Module Designer Grill Standard Grill Assembly Assembly Driver Module...
  • Page 15: Product Details

    Product Details Versatile mounting tabs – allows for variance in wall construction Driver module accepts mounting of both standard and designer grill Complete In-Wall Assembly Air tight coupling, with easy installation hardware Gold plated spring loaded binding posts to hold and lock wire in place...
  • Page 16: Retro Fit Installation

    In-Wall Subwoofer The In-Wall Subwoofer ships ready to install for both... New Construction Installation - and - Retro Fit Installation...
  • Page 17: New Construction Installation

    New Construction Installation Step 1 – Get to the Wall Step 2 – Install Cabinet Module and Mudring...
  • Page 18 New Construction Installation Step 3 – Run wire from Velodyne Amplifier, thru wall, to location where driver module will install...
  • Page 19 New Construction Installation Step 4 – Finish Wall Step 5 – Install Driver Module...
  • Page 20 New Construction Installation Step 6 – Driver Module Installed...
  • Page 21 New Construction Installation Step 7 – Install Grill Frame...
  • Page 22 New Construction Installation Step 8 – Install Standard Metal Grill...
  • Page 23 Step 1 – Get to the Wall Retro Fit Installation Step 2 – a) Decide on grill location and cabinet orientation. Typically the unit will be “downward firing” with the grill near the floor b) Cut opening in drywall using included template...
  • Page 24 Retro Fit Installation Step 3 – Install Cabinet module...
  • Page 25 Retro Fit Installation Step 4 – Run wire from Velodyne amplifier, thru wall, to driver module...
  • Page 26 Retro Fit Installation Step 5 – Install filler plate Step 6 – Install ½ inch drywall Step 7 – Mud, tape, texture and painting...
  • Page 27 Retro Fit Installation Step 8 – Install plastic grill housing...
  • Page 28 Retro Fit Installation Step 9 – Install metal grill...
  • Page 29 • Use both modules for retro fit • Expect high performance, minimal vibration • Run 1 or 2 subwoofers off same amp • Use standard grill for easy servicing; designer grill for interior designer acceptance • Paintable grill In-Wall Subwoofer...
  • Page 30 Question Question & & Answer Answer...
  • Page 31 The SubContractor Series Thank you for attending “Introducing the New SubContractor Subwoofer Series” Webinar For more information contact your local Velodyne representative or visit us at www.velodyne.com...
