Velodyne SUBCONTRACTOR SC-600 IF/IC Installation Manual
In-floor/in-ceiling
Hide thumbs
Also See for SUBCONTRACTOR SC-600 IF/IC:
- User manual (24 pages) ,
- Brochure & specs (4 pages) ,
- Specifications (1 page)
Related Manuals for Velodyne SUBCONTRACTOR SC-600 IF/IC
Summary of Contents for Velodyne SUBCONTRACTOR SC-600 IF/IC
- Page 1 SC-600 IF/IC (In-Floor/In-Ceiling) Subwoofer SubContractor Series I N S T A L L A T I O N M A N U A L...
- Page 2 w w w . v e l o d y n e . c o m SC-600 IF/IC User’s Manual...
- Page 3 Ta b l e o f C o n t e n t s Product Overview...1 Installation — Step-By-Step ...2 Velodyne Products ...10 w w w . v e l o d y n e . c o m SC-600 IF/IC User’s Manual...
- Page 4 P r o d u c t O v e r v i e w The SC-600 IF/IC is an affordable in-ceiling or in-floor subwoofer that offers outstanding performance and value. The SC-600 IF/IC sports a powerful 12” driver and slot-loaded, bass reflex cabinet enabling maximum performance to reproduce the most demanding home theater and music with authority, accuracy and low distortion.
- Page 5 I n s ta l l a t i o n — S t e p - B y - S t e p Step 1 - Determine installation location. As stated above, the SC-600 IF/IC can be mounted virtually anywhere.
- Page 6 Step 3 - Determine and mark grille location. From the centerline of the subwoofer driver, mark off the dimensions of the grille opening to accommodate the decorative grille chosen for the end user installation. Step 4 - Prepare the installation location. Make whatever modifications are required to enable the subwoofer to fit in the installation location.
- Page 7 Step 6 - Install. Place the SC-600 IF/IC as determined in step two and attach the brackets loosely. CAUTION: The SC-600 IF/IC is heavy. Either use a partner to suspend the subwoofer while you are attaching it or use a mechanical device to hold it in place during installation. Figure 3: SC-600 IF (In-Floor) positioned into floor location.
- Page 8 Step 7 - Adjust bracket position and tighten. Position the subwoofer into its final location and tighten the brackets. Figure 4: Tighten the brackets. w w w . v e l o d y n e . c o m SC-600 IF/IC User’s Manual...
- Page 9 Step 8 - Secure wiring. Attach the speaker wire to the speaker terminals. Twist the wire strands tightly before inserting them in the terminals. Do not allow stray wires from one terminal to touch the other terminal. This will damage the amplifier. A 16 AWG or heavier wire is recommended. Be sure to secure the speaker wire so it does not rattle or buzz against the cabinet during use.
- Page 10 Step 9 - Complete installation. Install the decorative grille and perform any other tasks needed to complete the installation based on chosen woofer positioning. It is recommended to use caulking to secure the decorative grille to prevent buzzing and rattling. Figure 6: Finished installation with register Step 10 - Use aggressive bass material and check the subwoofer for buzzes and rattles.
-
Page 11: To Obtain Service
LIMITED WARRANTY - U.S. AND CANADA ONLY VELODYNE ACOUSTICS, Inc. (“VELODYNE”) warrants all electronics for a period of three years, drivers for a period of five years, and full range speakers for a period of five years. All VELODYNE products have a warranty from the... - Page 12 V e l o d y n e P r o d u c t s 120V ® DD Series DD-10 DD-12 DD-15 DD-18 Digital Drive 1812 Signature Edition DEQ-R Series DEQ-8R DEQ-10R DEQ-12R DEQ-15R DLS™-R Series DLS -3500R DLS -3750R DLS -4000R DLS -5000R Impact Series...
- Page 13 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax www.velodyne.com Service E-mail: service@velodyne.com Product E-mail: help@velodyne.com Technical E-mail: techhelp@velodyne.com 63-SC600IFC Rev A JUL08 w w w . v e l o d y n e . c o m...
