  • Page 1 SC-IW (In-Wall) Subwoofer SubContractor Series I N S T A L L A T I O N M A N U A L...
  • Page 2 C a u t i o n ! w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 3 At t e n t i o n ! w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 4 Vo r s i c h t ! w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 5 At t e n z i o n e ! w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 6: Table Of Contents

    New Construction Installation - Designer Grille ...15 Retro-Fit Installation - Designer Grille ...25 Retro-Fit Installation - Standard Grille ...38 Other Velodyne Subwoofer Products ...53 w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 7: Product Overview

    P r o d u c t O v e r v i e w The SC-IW (In-Wall) subwoofer can be installed in a variety of locations and positions in any given installation. Although this product is extremely versatile and flexible in its uses, it has been specifically designed for two major applications - New Construction Installations and Retro-Fit Installations in structures made of traditional 2x4 studs with 16 inch spacing, on-center.
  • Page 8 The SC-IW consists of two cabinets — the “driver module” and the “back box.” (a.k.a. the “Enclosure”). Unlike other in-wall products where a back box may be optional, the SC-IW requires both enclosures, unaltered, for every installation. In new construction situations, the back box is in installed first (for example, at the framing or rough out stage), and the driver module is installed later in the trim out stage.

  • Page 9: Installation Overview

    I n s ta l l a t i o n O v e r v i e w You must first decide how the SC-IW is to be installed — whether new or retrofit installation, and whether you are using the standard or designer grille. Remember that in all cases the grille can be painted to match the room’s de ´cor.

  • Page 10: New Construction Installation - Standard Grille

    Note: This installation process assumes that the installer has access to the open framed 2x4 studded wall with 16 inch spacing. In the event that the stud spacing is larger, an additional 2x4 or other spacer can be used to fill the space between the SC-IW back box and the neighboring stud.
  • Page 11 Once the mudring and the back box are aligned, install the back box as shown. Figure 2: Install Back Box w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 12 Step 3 - Route Wire Route the wire from the location where the electronics gear is located to where the SC-IW will be. There is "extra space" between the studs and the back box in the event that the wire has to pass along the side of the back box to the driver module.
  • Page 13 Once the wall is finished, the installer must revisit the installation site and verify that the contractors have properly used the mudring as their guide leaving an opening that is approximately 16 1/2” x 13 1/4”. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 14 At this point, the mudring can be removed. It should be easily removed by "pulling it through" the drywall opening. After it is removed, discard. Figure 5: Remove Mudring w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 15 Please see picture below. Screw must face outward Figure 6: Clamp Ring Placement w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 16 Be sure to properly tighten all clamps. Test the seal by listening to the connection with test audio material after the install is complete. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 17 Note: The grille can be painted to match the de´ cor. The supplied paint mask can be used to paint the grille frame while the metal grille insert can be painted separately. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 18 Tighten using the supplied allen wrench. Figure 9: Grille Frame Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 19 Install two pan head phillips screws (provided) into standard grille into bottom left and bottom right holes. Figure 10: Secure Grille w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 20 The installation is complete. Test the installation with bass audio material and check for buzzes, rattles, and air leaks and address accordingly. Figure 12: Completed Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 21: New Construction Installation - Designer Grille

    Note: This installation process assumes that the installer has access to the open framed 2x4 studded wall with 16 inch spacing. (In the event that the stud spacing is larger, an additional 2x4 or other spacer can be used to fill the space between the SC-IW back box and the neighboring stud.)
  • Page 22 Step 2 - Mark Installation Location Measure from the bottom (or top if the SC-IW is to fire upwards) of the designer grille’s lowest (or highest) position 6 3/8” up along the stud and mark the stud in this location. This location will determine the bottom edge of the bracket on the driver module.
  • Page 23 Step 3 - Route Wire Route the wire from the location where the electronics gear is located to where the SC-IW will be. There is "extra space" between the studs and the back box in the event that the wire has to pass along the side of the back box to the driver module.
  • Page 24 Step 4 - Secure Subwoofer to Wall After the location has been determined, securely fasten the subwoofer to the studs. Velodyne provides 12 screws for this purpose. Figure 16: Secure Subwoofer w w w . v e l o d y n e . c o m...
  • Page 25 Step 5 - Connect Speaker Wire to Subwoofer Connect the previously routed speaker wire to the subwoofer taking care to match the positive wire to the red terminal and the negative wire to the black terminal. The spring loaded binding post will hold and secure the wire in place.
  • Page 26 Step 6 - Install Filler Panel Velodyne provides an MDF filler panel to fill the distance between the driver module and the drywall. This filler panel also acts as a guide for the standard grille. The filler panel easily installs using the four flat head screws and included allen wrench. Be sure to orientate the filler panel as shown such that the tapered edge faces way from the driver.
  • Page 27 Cut out the part of the installation template that outlines the designer grille. Affix the template to the studs at the bottom of the filler panel as shown. Figure 19: Template Place Holder Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 28 17 1/2” x 4 1/2”. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 29 Figures 21a and 21b: Designer Grille Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 30 Step 11 - Install Metal Insert into Plastic Grille Frame Figure 22: Metal Insert Installation Step 12 - Finished Grille Figure 23: Finished Grille Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 31: Retro-Fit Installation - Designer Grille

    Step 1 - Decide on Subwoofer Orientation and Grille Location The first decision for a retrofit installation is which way the subwoofer will face (up or down), and therefore where the designer grille will be located on the wall (near the floor or ceiling).
  • Page 32 Note: Two templates are provided, one for the designer grille and one for the standard grille. Be sure to use the correct template! w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 33 After the drywall is scored, remove the template and the drywall as indicated. The cutout after removal is shown in figures 26a and 26b. Figures 26a and 26b: Drywall Removal w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 34 Step 4 - Run Speaker Wire from Amplifier Location to In-Wall Subwoofer Route the wire from the location where the electronics gear is located to where the SC-IW will be. There is extra space between the studs and the box in the event that the wire has to pass along the side of the back box to the driver module.
  • Page 35 Figures 28a and 28b: Cabinet and Driver Module Assembly Note: Leave the paint cover on the driver to prevent damage during the installation, painting and finishing process. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 36 This location will determine the bottom edge of the bracket on the driver module. 6 3/8” Figure 29: Mark Installation Location w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 37 Step 7 - Install Subwoofer into Opening After the in-wall subwoofer assembly is complete, and the mounting position marked, orient the assembly inside the wall. In this installation example we have decided to face the unit downward. It is critical at this point that the top of the cabinet module is aligned with the top of the cutout and that the brackets are 6 3/8”...
  • Page 38 Step 8 - Secure Subwoofer to Wall After the location has been determined, securely fasten the subwoofer to the studs. Velodyne provides 12 screws for this purpose. Figure 31: Secure Subwoofer w w w . v e l o d y n e . c o m...
  • Page 39 Step 9 - Connect Speaker Wire to Subwoofer Connect the previously routed speaker wire to the subwoofer taking care to match the positive wire to the red terminal and the negative wire to the black terminal. The spring loaded binding post will hold and secure the wire in place.
  • Page 40 Step 10 - Install Filler Panel Velodyne provides an MDF filler panel to fill the distance between the driver module and the drywall. This filler panel also acts as a guide for the designer grille. The filler panel easily installs using the four flat head screws and included allen wrench.
  • Page 41 Note the grille can also be painted to match the de´ cor. Note: The paint cover should be remain on the driver until this step is complete. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 42 Figures 35a and 35b: Designer Grille Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 43 Step 14 - Install Metal Insert into Plastic Grille Frame Figure 36: Metal Insert Installation Step 15 - Finished Grille Figure 37: Finished Grille Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 44: Retro-Fit Installation - Standard Grille

    Step 1 - Decide on Subwoofer Orientation and Grille Location The first decision for a retrofit installation is which way the subwoofer will face (up or down), and therefore where the standard grille will be located on the wall (near the floor or ceiling).
  • Page 45 Note: Two templates are provided, one for the designer grille and one for the standard grille. Be sure to use the correct template! w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 46 After the drywall is scored, remove the template and the drywall as indicated. The cutout after removal is shown in figures 40a and 40b. Figures 40a and 40b: Drywall Removal w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 47 Step 4 - Run Speaker Wire from Amplifier Location to In-Wall Subwoofer Route the wire from the location where the electronics gear is located to where the SC-IW will be. There is extra space between the studs and the box in the event that the wire has to pass along the side of the back box to the driver module.
  • Page 48 Figures 42a and 42b: Cabinet and Driver Module Assembly Note: Leave the paint cover on the driver to prevent damage during the installation, painting and finishing process. w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 49 This location will determine the bottom edge of the bracket on the driver module. 5 3/8” Figure 43: Mark Installation Location w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 50 Step 7 - Install Subwoofer into Opening After the in-wall subwoofer assembly is complete, orientate the assembly inside the wall. In this installation example we have decided to face the unit downward. It is critical at this point that the top of the cabinet module is aligned with the top of the cutout and that the brackets are 5 3/8”...
  • Page 51 Step 8 - Secure Subwoofer to Wall After the location has been determined, securely fasten the subwoofer to the studs. Velodyne provides 12 screws for this purpose. Figure 45: Secure Subwoofer w w w . v e l o d y n e . c o m...
  • Page 52 Step 9 - Connect Speaker Wire to Subwoofer Connect the previously routed speaker wire to the subwoofer taking care to match the positive wire to the red terminal and the negative wire to the black terminal. The spring loaded binding post will hold and secure the wire in place.
  • Page 53 Step 10 - Install Filler Panel Velodyne provides an MDF filler panel to fill the distance between the driver module and the drywall. This filler panel also acts as a guide for the standard grille. The filler panel easily installs using the four flat head screws and included allen wrench. Be sure to orientate the filler panel as shown such that the tapered edge faces way from the driver.
  • Page 54 Step 12 - Tape, Mud, Texture and Paint Wall After the Velodyne subwoofer is installed into the wall, the wall should be taped, textured, blended and then painted to match the existing wall. It is not required to finish the filler plate as it will be removed in the next step.
  • Page 55 Remove the filler plate. Obtain the standard grille with integrated scoop and remove metal grille insert, as shown, in the picture below. Figure 49: Metal Grille Insert Removal w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 56 Tighten using the supplied allen wrench. Figure 50: Grille Frame Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 57 Install two pan head phillips screws (provided) into standard grille into bottom left and bottom right holes. Figure 51: Secure Grille w w w . v e l o d y n e . c o m SC-IW Installation Manual...
  • Page 58 The grille can also be painted to match the de´ cor if desired. Figure 53: Completed Installation w w w . v e l o d y n e . c o m SC-IW Installation Manual...

  • Page 59: Other Velodyne Subwoofer Products
