Summary of Contents for Velodyne SC-602
- Page 1 SC-602 Amplifier SubContractor Series ™ U S E R ’ S M A N U A L S C - 6 0 2 A m p l i f i e r, S C - 6 0 0 I W,...
- Page 2 120-volt version to 230-volts or vice-versa. This will result in damage to the subwoofer and possible injury to the user. CAUTION: To prevent electrical shock, match wide blade of plug to wide slot, fully inserted. w w w . v e l o d y n e . c o m SC-602 Amplifier User’s Manual...
-
Page 3: Table Of Contents
– SC-602 Subwoofer Amplifier ........ -
Page 4: Congratulations
• Blue power indicator LED • RS-232 Serial Interface • 12 Volt trigger • Universal IR repeater mini-jack • Model-specific subsonic filter w w w . v e l o d y n e . c o m SC-602 Amplifier User’s Manual... -
Page 5: Sc-600 Iw, Sc-600 If/Ic Subwoofers
Remember to perform all installation procedures with system power turned off. w w w . v e l o d y n e . c o m SC-602 Amplifier User’s Manual... -
Page 6: Installation
(1) Power Switch This button forces your SC-602 amplifier into standby mode. The power LED turns amber, the numeric LED shuts off, and the amplifier puts out no power. The unit will remain in this mode until the POWER button is pressed again. -
Page 7: Rear Panel Connections
This LED supplies information on volume, crossover, woofer type, and other information. The light button on the remote deactivates this display. Upon startup, the display shows the model of subwoofer the SC-602 amp is set to, then reverts to the volume indicator. (7) Volume Control These buttons allow you to balance the output from the subwoofer with the output of the main speakers in your system. - Page 8 Figure 2A: Mono (LFE) Line-Level Connection. Option 2 Stereo Line-Level Output to Another System, e.g. a second SC-600 or SC-602 amplifier Stereo Line-Level Input from Source Figure 2B: Stereo Line-Level Connection. w w w . v e l o d y n e . c o m...
- Page 9 An example of a speaker-level connection is shown in Figure 3. Caution!!! To avoid damage to your SC-602 amp and subwoofer, be sure to maintain correct polarity when making all speaker connections; red (positive) to red, and black (negative) to black. Be sure that all connections are tight, and that there are no loose strands or frayed wires.
- Page 10 Figure 3: Speaker-Level Connection. (17) and (18) Subwoofer Line Level (LFE) Connection Terminals Connect the output terminals to the subwoofer being controlled by the SC-602 amplifier. Only connect ONE subwoofer to each red/black pair of subwoofer output terminals - DO NOT connect multiple subwoofers to the terminals in any configuration.
- Page 11 . v e l o d y n e . c o m SC-602 Amplifier User’s Manual...
-
Page 12: Rear Panel Connections - Detailed Explanation
A B O U T L O W - P A S S C R O S S O V E R S All of the SC-602 amplifier inputs sum the left and right channels together and the resulting signal is passed through an adjustable low-pass crossover before being amplified. The crossover control allows you to adjust the upper limit of the subwoofer’s frequency response from 30 to... -
Page 13: A Word About Interconnect Cables
In these installations, you may want to bypass the crossover in either the processor or the Velodyne SC-602 amplifier as described above. However, in some cases you may want to use BOTH crossovers. If you choose to do this you should stagger the frequencies, (i.e., 120 Hz subwoofer, 80 Hz processor) for best results. -
Page 14: Selecting The Subwoofer To Be Controlled
SC-602 amplifier with the subwoofer it is controlling. The SC-602 amplifier comes with a default setting for the SC-600 IW subwoofer. When the unit is first powered up, the model setting is displayed for two seconds on the numeric LED before the display reverts to the volume setting. -
Page 15: Usage
Note: Each time the EQ feature is utilized, the EQ settings for the SC-602 amplifier are reset. If the microphone is not plugged in, the SC-602 amplifier will emit one or two sweep tones then cease the EQ operation. In this case, the previous EQ settings will be preserved. - Page 16 Each preset has its own characteristics with respect to subsonic filter, volume differential and a single contour equalizer in order to optimize the listening mode for the preset. w w w . v e l o d y n e . c o m SC-602 Amplifier User’s Manual...
- Page 17 Jazz – Classical R&B – Rock R&B – Rock R&B – Rock Jazz – Classical Jazz – Classical Jazz – Classical Jazz – Classical R&B – Rock R&B – Rock R&B – Rock or Jazz – Classical Games SC-602 Amplifier User’s Manual...
-
Page 18: Restore Defaults
R e s t o r i n g D e fa u l t s There is a feature that allows you to restore default settings for your SC-602 amplifier. By pressing presets in EXACTLY the following order on the remote, the unit’s power light will blink indicating that you have restored defaults. -
Page 19: Troubleshooting And Service
3. The unit has been exposed to water 4. Some part of the chassis or circuitry is physically damaged Thank You for Purchasing an SC-602 Amplifier! w w w . v e l o d y n e . c o m... -
Page 20: Specifications
S p e c i f i c a t i o n s w w w . v e l o d y n e . c o m SC-602 Amplifier User’s Manual... -
Page 21: Appendix A: Rs-232 Serial Overview And Commands
. v e l o d y n e . c o m Notes Header Character 3 to 4 ASCII characters see formats below Case sensitive - CAPS ONLY! Termination Character (required or command is ignored) SC-602 Amplifier User’s Manual ®... - Page 22 #MU1$ 1: Mute On #MU?$ 0: Power Off #JU0$ 1: Power On #JU1$ #JU?$ SC-602 Amplifier User’s Manual Comments Sets volume to a value, increments volume up or down, or requests current volume setting Activates the indicated preset, or requests...
-
Page 23: Velodyne Products
DD-10 SPL-800i DD-12 SPL-1000i DD-15 DD-18 SPL-Ultra Series SPL-800 Ultra SPL-1000 Ultra SPL-1200 Ultra CHT-8Q SubContractor™ CHT-10Q Series CHT-12Q SC-1250 CHT-15Q SC-10 SC-12 SC-15 SC-IW SC-IF/IC SC-600 Amp SC-602 Amp SC-600 IW SC-600 IF/IC SMS™ -1 SC-602 Amplifier User’s Manual... -
Page 24: To Obtain Service
LIMITED WARRANTY - U.S. AND CANADA ONLY VELODYNE ACOUSTICS, Inc. (“VELODYNE”) warrants all electronics for a period of three years, drivers for a period of five years, and full range speakers for a period of five years. All VELODYNE products have a warranty from the date of purchase... - Page 25 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax www.velodyne.com Service E-mail: service@velodyne.com Product E-mail: help@velodyne.com Technical E-mail: techhelp@velodyne.com 63-SC602 RevA SEP 2009 w w w . v e l o d y n e . c o m...
