- Page 1 GEBRAUCHSANLEITUNG Gebrauchsanleitung Operating instructions Notice d'utilisation Istruzioni per l' uso Gebruiksaanwijzing Instrucciones de uso Instruções de serviço Ïäçãßåò ÷ñÞóçò KE9700-0-2TZ IKE 249 5...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.
-
Page 3: Table Of Contents
CONTENTS 5 Using your refrigerator 12 1 The refrigerator Indicator Panel ......... 12 2 Important Safety Egg tray ........... 13 Warnings Sliding Body Shelves ....... 13 Intended use ........4 Chiller compartment ......14 General safety ........4 Door Open Warning ......14 Child safety ........ -
Page 4: The Refrigerator
The refrigerator A- Fridge compartment B- Freezer compartment 1- Butter & Cheese shelf 2- Fridge compartment door shelves 3- Fridge compartment glass shelves 4- Diffuser cover 5- Illumination lens 6- Movable middle section 7- Chiller compartment 8- Bottle shelf 9- Crisper 10- icebox 11- Movable separators Figures that take place in this instruction manual are schematic and may... -
Page 5: Important Safety Warnings
Important Safety Warnings Please review the following • Vapor and vaporized cleaning information. If these are not followed, materials should never be used in personal injury or material damage cleaning and defrosting processes of may occur. Otherwise, all warranty and your refrigerator. - Page 6 • This product manual should be • Do not use mechanical devices passed to the next owner of the or other means to accelerate the refrigerator if the owner changes. defrosting process, others than those • When moving the refrigerator make recommended by the manufacturer.
-
Page 7: Child Safety
• If refrigerator will not be operated for Ignore the warning if your product an extended period of time it should is equipped with a cooling system be unplugged. A problem in electrical that contains R134a. cable insulation may result in fire. You can see the gas used in •... -
Page 8: Installation
Installation 2. You can install the 2 plastic wedges C Please remember that the as illustrated in the figure. Plastic manufacturer shall not be held liable if wedges will provide the required the information given in the instruction distance between your refrigerator manual is not observed. -
Page 9: Electric Connection
Electric connection Disposing of your old refrigerator Connect your refrigerator to a grounded socket which is being Dispose of your old machine without protected by a fuse with the giving any harm to the environment. appropriate capacity. A You may consult your authorized Important: dealer or waste collection center of B The connection must be in... -
Page 10: Placing And Installation
Placing and Installation Floor balance adjustment A Caution: Never plug the refrigerator A If your refrigerator is unbalanced; into the wall outlet during installation. 1- Ventilation cover is removed by Otherwise, risk of death or serious unscrewing its screws as illustrated injury may arise. -
Page 11: Adjusting The Gap Between The Upper Door
Adjusting the gap between the upper door C Fix the door you have adjusted by tightening the screws without changing the position of the door. C You can adjust the gap between the fridge compartment doors as illustrated in the figures. Door shelves should be empty when adjusting the door height. -
Page 12: Preparation
Preparation Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. The ambient temperature of the room where you install your refrigerator should at least be 10°C. -
Page 13: Using Your Refrigerator
Using your refrigerator Indicator Panel Indicator panel aids in using your refrigerator with its audio and visual functions. 1. Freezer Compartment Temperature Indicator 2. Error Status Indicator 3. Fridge Compartment Temperature Indicator 4. Fridge Compartment Temperature Setting Button 5. Economy Mode Indicator 6. -
Page 14: Egg Tray
Egg tray 1. Freezer Compartment Temperature Indicator You can install the egg holder to the It indicates the temperature set for desired door or body shelf. Freezer Compartment. Never store the egg holder in the freezer compartment 2. Error Status Indicator If your refrigerator does not cool adequately or if there is a sensor Sliding Body Shelves... -
Page 15: Chiller Compartment
Chiller compartment Door Open Warning Chiller compartments enable the An audio warning will be given when foods to be frozen become ready the fridge or freezer compartment for freezing. You can also use these door of your product is left open for compartments to store your food at a a certain period of time. -
Page 16: Freezing Fresh Food
Fridge Freezer Compartment Compartment Explanations Adjustment Adjustment -18°C 4°C This is the normal recommended setting. These settings are recommended when the ambient -20,-22 or -24°C 4°C temperature exceeds 30°C. Use when you wish to freeze your food in a short Quick Freeze 4°C time. -
Page 17: Placing The Food
Deep-freeze information Defrosting The freezer compartment defrosts Food must be frozen as rapidly as automatically. possible when they are put in a Placing the food refrigerator in order to keep them in good quality. Various frozen food The TSE norm requires (according to Freezer such as meat, fish, certain measurement conditions) the... -
Page 18: Crisper
Crisper Crisper of your refrigerator is designed specially to keep your vegetables freshly without loosing their humidity. For this purpose, cool air circulation occurs around the crisper in general. Remove the door shelves that align with the crisper before removing the crispers. -
Page 19: Movable Middle Section
Movable Middle Section Movable middle section is intended to prevent the cold air inside your refrigerator from escaping outside. 1- Sealing is provided when the gaskets on the door presses on the surface of the movable middle section while the fridge compartment doors are closed. -
Page 20: Telescopic Drawer
Telescopic Drawer Pay attention not to squeeze any parts of your body such as hands, feet and etc. between the movable parts while the drawer is in use in order to avoid any injury. You can remove the partition in the drawer as illustrated when you want to clean it. -
Page 21: Maintenance And Cleaning
Maintenance and cleaning A Never use gasoline, benzene or similar substances for cleaning purposes. B We recommend that you unplug the appliance before cleaning. B Never use any sharp abrasive instrument, soap, household cleaner, detergent and wax polish for cleaning. C Use lukewarm water to clean the cabinet of your refrigerator and wipe it dry. -
Page 22: Recommended Solutions For The Problems
Recommended solutions for the problems Please review this list before calling the service. It might save you time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. - Page 23 The fridge is running frequently or for a long time. • Your new product may be wider than the previous one. This is quite normal. Large refrigerators operate for a longer period of time. • The ambient room temperature may be high. This is quite normal. •...
- Page 24 Vibrations or noise. • The floor is not even or it is weak. The refrigerator rocks when moved slowly. Make sure that the floor is strong enough to carry the refrigerator, and level. • The noise may be caused by the items put onto the refrigerator. Items on top of the refrigerator should be removed.
- Page 25 48 9326 0000/AA...
