Refrigerator - Freezer
Refrigerator with freezer is for domestic use
only.
The lower part of the appliance is refrigerator
and is used for storing fresh foods at the
temperature of 0°C and higher.
The upper part is freezer and is used for
freezing fresh foods and storing frozen foods for
longer periods of time (up to one year, depending
on the kind of foods you store). The compartment
is marked with four stars.
Before Putting Into Use .................................22
Instructions for Use
Mounting Instructions
We Care for the Environment
Tips for Energy Savings
Important........................................................23
Disposing of the Worn Out Appliance
Placing and Installation.................................24
Choosing the Right Place
Connection to Power Supply
Description of the Appliance ........................25
Operation Control .........................................27
Temperature Selection
Use ...................................................................28
Storing Fresh Foods
Instructions for use and installation instructions
Freezing Fresh Foods
Storing Frozen Foods
Defrosting Frozen Food
How to make ice cubes
Maintenance and Cleaning........................... 31
Automatic Defrosting of the Refrigerator
Manual Defrosting of the Frezing Compartment
Cleaning the Appliance
Switch Off the Appliance When Not In Use
Trouble-Shooting Guide............................... 32
Mounting Dimensions and Required Air
Circulation
Changing the Direction of Opening
the Door.......................................................... 35
Mounting the Appliance ............................... 36
21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Küppersbusch refrigerator - freezer
Summary of Contents for Küppersbusch refrigerator - freezer
- Page 1 Refrigerator - Freezer Refrigerator with freezer is for domestic use only. The lower part of the appliance is refrigerator and is used for storing fresh foods at the temperature of 0°C and higher. The upper part is freezer and is used for...
-
Page 2: Before Putting Into Use
Before Putting Into Use Before connecting the appliance to the mains Use higher thermostat settings only when supply, place it on the location where it will later required or recommended. on be installed and leave it for about 2 hours, Before loading the appliance with packages of which will reduce a possibility of malfunctions in fresh foods, make sure they are cooled to... - Page 3 Important If you have bought this appliance to replace an Disposing of the Worn Out old one equipped with a lock that cannot be Appliance opened from inside (lock, bolt), make sure that the lock is broken. This will make it impossible for children to lock themselves inside the When your appliance finally wears out, dispose appliance and suffocate.
-
Page 4: Placing And Installation
Placing and Installation The appliance should be positioned at least 3 cm Choosing the Right Place away from the electric or gas cooker and at least 30 cm away from the oil or coal stove. If this is Place the appliance in dry and regularly ventilated not possible, use an appropriate insulation. -
Page 5: Description Of The Appliance
Description of the Appliance out. If you want to remove it, slightly lift up the Refrigerator (A) back part and pull it out. Refrigerator is used for storing fresh foods for few Glass shelves (some models only have them) are days. - Page 6 Door Liner The door liner consists of various shelves or holders used for storing eggs, cheese, butter and yogurt as well as other smaller packages, tubes, cans etc. The lower shelf is used for storing bottles. Illumination in the Interior of the Refrigerator The light for illuminating the interior of the appliance is on, when the door is opened.
-
Page 7: Operation Control
Operation Control The appliance is controlled with thermostat knob, situated in the right upper part inside the appliance. Turn the knob clockwise from STOP (0) position towards 7 and backwards. Temperature Selection Higher settings on the knob (towards 7) mean lower temperatures (colder) in all three compartments of the appliance. -
Page 8: Storing Fresh Foods
cause damages when in contact with plastic Storing Fresh Foods surfaces or gaskets for longer period of time. Foods should be cooled down before storing. Proper use of the appliance, adequately packed Crispy and delicate foods should be stored in food, correct temperature and taking into account the coldest parts of the refrigerator. -
Page 9: Freezing Fresh Foods
Freezing Fresh Foods Carefully select food you intend to freeze; it should be of adequate quality and suitable for freezing. Use correct packaging and wrap it right. The packaging should be air tight and shouldn't leak since this could cause substantial vitamin loss and dehydration of foods. -
Page 10: How To Make Ice Cubes
Defrosting Frozen Food Partially thawed or defrosted foods should be used as soon as possible. Cold air preserves the food but it does not destroy microorganisms which rapidly activate after defrosting and make foods perishable. Partial defrosting reduces the nutritional value of foods, especially of fruits, vegetables and ready- made meals. -
Page 11: Maintenance And Cleaning
Maintenance and Cleaning Every now and then wipe the condenser on the Automatic Defrosting of the rear wall. Use soft non-metal brush or vacuum Refrigerator cleaner. There is no need to defrost the refrigerator, because ice depositing on the inner back wall is defrosted automatically. -
Page 12: Troubleshooting Guide
Trouble-Shooting Guide During the service, you can come across some Water is Leaking From the troubles that in most cases result from improper Refrigerator handling of the appliance and can easy be eliminated. In case the discharge water outlet is clogged, or the defrost water drips over the channel, water The Appliance Fails to Operate After leaks from the refrigerator. -
Page 13: Bulb Replacement
Bulb Replacement Before replacing the light bulb, disconnect the appliance form the power supply. Press the cover at the rear side (in the arrow 1 direction) and remove the plastic cover (in the arrow 2 direction). Replace the bulb with a new one (E14, max. -
Page 14: Mounting Instructions
Mounting Instructions Mounting instructions for refrigerating and Mounting Dimensions and freezing appliances are for qualified technicians Required Air Circulation only. Appliance should be mounted and installed in compliance with The rear wall of the appliance is getting warm these instructions, current standards and during the operation of the appliance (and water regulations. -
Page 15: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door If you find the direction of opening the door on your appliance inconvenient, you can change it. Holes on the opposite side have already been prepared in the factory and are now plugged. Remove the cover of the upper hinge, unscrew the hinge and take off the door (the door is not fixed on the lower hinge). -
Page 16: Mounting The Appliance
Mounting the Appliance Push the appliance for some 38 mm into the kitchen unit and allow at least 4 mm free space on both sides between the appliance and the side walls of the kitchen unit (Fig. 1). Widely open the door and put it together with the kitchen unit door.
