Summary of Contents for Kuppersbusch GEH 640.0
-
Page 2: Your Cooker At A Glance
Factory setting / conversion possibilities ..34 Table of permissible types of gas and pressures Table of injector sets Conversion injector sets Table of heat input Gross calorific values according to EN 437 Resetting the ring burners Resetting the oven burner Final assembly GEH 640.0... - Page 3 Cover plate for oven burner Oven door Auxiliary ignition hole Viewing hole Available accessories: Ring for small pots acc. no. 160 Roasting grid acc.-no. 440 Roasting tray acc.-no. 441 Drip pan acc.-no. 543 Baking tray, alu acc.-no. 542 backmobil acc.-no. 600 GEH 640.0...
-
Page 4: Disposing Of The Packaging And The Old Appliance
The ventilation slits in the hob should not be covered over. If cracks, fractures or any other defects appear in your glass ceramic hob, immediately switch off the appliance. Disconnect the fuse. GEH 640.0... - Page 5 To switch off the signal, briefly press one of the setting keys. Unless the signal is switched off by hand, it automatically stops after ap- prox. 2 minutes. The cooking symbol flashes until the alarm is switched off. GEH 640.0...
- Page 6 The cooling fan can continue to run after the oven has been switched off, that is to say it switches itself back on because of the residual heat! GEH 640.0...
- Page 7 The oven burner continues at maximum set- ting until the selected temperature has been reached. If at any time the flame does not light successfully, open the oven door and ventilate, then ignite once more. GEH 640.0...
- Page 8 Baking moist cakes can produce steam, which forms condensation in the oven. Most escapes through the vapour channel and can collect on kitchen tiles and fronts of units as condensation. This is necessary physically. GEH 640.0...
- Page 9 8 - 12 Preheat to 250 °C two baking trays pizza 0 + 3 10 - 14 Preheat to 250 °C 2 trays 2nd and 6th shelf position from bottom 3 trays 1st, 4th and 7th shelf position from bottom GEH 640.0...
- Page 10 2. or 3. shelving rail from the bottom. ® Sliding the backmobil into the oven: Slide in slowly until it locks int GEH 640.0...
- Page 11 Take hold of the oven door on both si- des and push the hinges into the rele- vant holes on the oven. Very slowly open the oven door. Fold down the clamps on the door hin- ges. Close the oven door. GEH 640.0...
-
Page 12: Planning The Supply Lines
The joint must be provided with a stop cock and be accessible. Electrical connection For the power supply to the oven and the electric automatic spark ignition a Model designation hob 230-240 shockproof socket is required. The appliance is supplied with a connection cable. GEH 640.0... -
Page 13: Installing The Cooker Into Your Fitted Kitchen
Make absolutely certain that the hose does not touch any parts of the appliance which become hot during cooking! Fastening in the appliance Open the oven door. Using the screws provided and slanting them outwards, fasten the appliance to the cabinet. GEH 640.0... -
Page 14: Installing The Glass Ceramic Gas Hob
- Attach the separate fume duct on the rear of the worktop recess with - Place the burner cover and at- the enclosed screws 4.2 x 16 mm. tachment carefully in the cor- rect position. Turn the cover to bring into position. Burner cover Attachment GEH 640.0... -
Page 15: Installation Into The Hob
- Then align the hob and fasten to the appliance with screws 4.2 x 32 mm and washers through the remaining free hole at each burner loca- Ignite the burner and test the stability of the flame. tion. The flame should be steady. GEH 640.0... -
Page 16: Table Of Permissible Types Of Gas And Pressures
G 20 (20/25 mbar) Natural gas LL G 25 (20 mbar) Natural gas L G 25 (25 mbar) Liquefied gas butane/propane G 30(50 mbar) Liquefied gas butane/propane G 30 (28-30/37 mbar Liquefied gas propane G 31 (50 mbar) GEH 640.0... -
Page 17: Conversion Injector Sets
The flow rate is calculated as follows: - Undo screws, replace low-set- flow rate l/min = heat input kW x 1000 ting injectors, tighten screws. gross calorific value kWh/m x 60 GEH 640.0... - Page 18 The readjustment is carried out at the oven thermostats. The operation fas- cia must first be removed. For natural gas and liquified petroleum gas Unscrew the injector and replace it by the new injector. Screw in the new in- jector as far as it will go. GEH 640.0...
