Summary of Contents for Kuppersbusch GEH 630.0
-
Page 2: Your Cooker At A Glance
Factory setting / conversion possibilities ..30 Table of permissible types of gas and pressures Table of injector sets Conversion injector sets Table of heat input Gross calorific values according to EN 437 Resetting the ring burners Resetting the oven burner Final assembly GEH 630.0... - Page 3 Cover plate for oven burner Oven door Auxiliary ignition hole Viewing hole Available accessories: Ring for small pots acc. no. 160 Roasting grid acc.-no. 440 Roasting tray acc.-no. 441 Drip pan acc.-no. 543 Baking tray, alu acc.-no. 542 backmobil acc.-no. 600 GEH 630.0...
-
Page 4: For Connection And Functions
The ventilation slits in the hob should not be covered over. If cracks, fractures or any other defects appear in your glass ceramic hob, immediately switch off the appliance. Disconnect the fuse. GEH 630.0... -
Page 5: Switching The Cooking Zones On And Off
- Turn the cooking zone regulator clockwise to zero setting. All cooking zone burners are protected thermoelectrically. If at any time the flame is extinguished unintentionally (e. g. due to pans boiling over or due to a strong draught), the gas supply switches off automatically. GEH 630.0... -
Page 6: Thermostat Settings
The resulting build-up of heat will impair the baking or roasting results and will damage the enamel. Gridirons: Please make sure that the lock-in posi- tion of the gridirons always faces the front (towards you). GEH 630.0... -
Page 7: Bottom Heat
Macaroons 140-150 20-45 Puff pastry Puff pastry 200-220 15-30 Yeast puff pastry 200-225 30-45 Curd cheese puff pastry 200-225 30-45 Shortcrust pastry 220-240 30-40 Curd cheese oil dough 200-210 20-50 Honey cake 175-190 20-35 Rye bread 200-220 50-60 GEH 630.0... - Page 8 Mutton chop 8-10 Lamb chop 8-10 Half a chicken 10-12 (500 g each) Fish fillet Trout (200 – 250 g each) Toast ® Sliding the backmobil into the oven: Slide in slowly until it locks int Topped toast snacks GEH 630.0...
- Page 9 Take hold of the oven door on both si- des and push the hinges into the rele- vant holes on the oven. Very slowly open the oven door. Fold down the clamps on the door hin- ges. Close the oven door. GEH 630.0...
-
Page 10: Planning The Supply Lines
The joint must be provided with a stop cock and be accessible. Electrical connection Model designation hob For the power supply to the oven and the electric automatic spark ignition a 230-240 shockproof socket is required. The appliance is supplied with a connection cable. GEH 630.0... -
Page 11: Installing The Cooker Into Your Fitted Kitchen
Make absolutely certain that the hose does not touch any parts of the appliance which become hot during cooking! Fastening in the appliance Open the oven door. Using the screws provided and slanting them outwards, fasten the appliance to the cabinet. GEH 630.0... -
Page 12: Installing The Glass Ceramic Gas Hob
- Attach the separate fume duct on the rear of the worktop recess with - Place the burner cover and at- the enclosed screws 4.2 x 16 mm. tachment carefully in the cor- rect position. Turn the cover Burner to bring into position. cover Attachment GEH 630.0... -
Page 13: Installation Into The Hob
- Then align the hob and fasten to the appliance with screws 4.2 x 32 mm and washers through the remaining free hole at each burner loca- Ignite the burner and test the stability of the flame. tion. The flame should be steady. GEH 630.0... -
Page 14: Table Of Permissible Types Of Gas And Pressures
G 20 (20/25 mbar) Natural gas LL G 25 (20 mbar) Natural gas L G 25 (25 mbar) Liquefied gas butane/propane G 30(50 mbar) Liquefied gas butane/propane G 30 (28-30/37 mbar Liquefied gas propane G 31 (50 mbar) GEH 630.0... -
Page 15: Conversion Injector Sets
The flow rate is calculated as follows: flow rate l/min = heat input kW x 1000 gross calorific value kWh/m x 60 - Undo screws, replace low-set- ting injectors, tighten screws. GEH 630.0... -
Page 16: Final Installation
The readjustment is carried out at the oven thermostats. The operation fas- cia must first be removed. For natural gas and liquified petroleum gas Unscrew the injector and replace it by the new injector. Screw in the new in- jector as far as it will go. GEH 630.0...
