- Page 1 Bedienungsanleitung Instructions Booklet Mode d’emploi Libretto Istruzioni Gebruiksaanwijzing Manual de instrucciones Manual de Instruções EDIP 6650.0 EDIP 9650.0...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 CHARACTERISTICS Dimensions Hood Type Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Directional Air Outlet grille Flange ø 150 mm Closing element Ref. Q.ty Installation Components Screws 3,5 x 16 Screws 2,9 x 12,7 Q.ty Documentation Instruction Manual...
-
Page 5: Installation
INSTALLATION Drilling the Support surface and Fitting the Hood • The Hood can be fitted directly on the lower surface of the Wall Units (650 mm min. above the Cooker Top) using the snap-on Side Supports. • Make an opening on the lower surface of the Wall Unit, as indicated. -
Page 6: Ducted Version Air Exhaust System
Connections DUCTED VERSION AIR EXHAUST SYSTEM When installing the ducted version, connect the hood to the chimney using either a flexible or rigid pipe ø 150 mm, the choice of which is left to the installer. • Fix the pipe in position using sufficient pipe clamps (not supplied). -
Page 7: Control Panel
Control panel FUNCTIONS 0/1 Light Turns lighting on and off. 0/1 Motor First speed. When pressed for about 1 seconds the motor is switched off. Speed Second speed. Speed Third speed. Speed Fixed Max. speed Flashing Intensive speed. Suitable for the strongest cooking vapours and odours. The function becomes active when the button is pushed for about 2 seconds. -
Page 8: Maintenance
MAINTENANCE Cleaning the Comfort Panel • Open the Comfort Panel by turning the knobs provided. • Disconnect the lights connector. • Disconnect the panel from the hood canopy by sliding the lever out of the fixing pin, simultaneously freeing the other end of the panel from the fixing pin. -
Page 9: Odour Filters (Recirculation Version)
Odour filters (Recirculation version) REPLACING ACTIVATED CHARCOAL FILTERS • These filters are not washable and cannot be regenerated, must replaced approximately every four months of operation, or more frequently with heavy usage. • Open the Comfort Panel by turning the knobs provided.
