Summary of Contents for Crate Palomino V50
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ................3 The Front Panel ..............4 The Rear Panel ..............5 Important Information About Tubes and Tube Products ....6 A Brief History of Tubes ..........6 Tube Types and Usage ............6 The Nature of Tubes: Why (and When) to Replace Them ..7 The Importance of Proper Biasing ........8 Survival Tips for Tube Amplifiers ........9 Suggested Settings .............10... -
Page 3: Introduction
Like all Crate products, your V50 amplifier is designed by musicians and built using only the best components. Extensive testing confirms that this amplifier is the absolute best it can be. -
Page 4: The Front Panel
The Front Panel 12. REV 1: Use this to adjust the amount INPUT: Use this jack to connect of reverb for Channel 1. Fully counter- your guitar to the amplifier using a clockwise is “dry” (no reverb). Rotate shielded instrument cable. clockwise to increase the amount of VOLUME: Use this to adjust the output reverb. -
Page 5: The Rear Panel
The impedance switch voltage, power, and frequency require- (23) must be set to the 8 ohm position ments stated on the V50 rear panel. Do when a 16 ohm extension speaker is not attempt to defeat the safety ground used. -
Page 6: Important Information About Tubes And Tube Products
Important Information about Tubes and Tube Products: A Brief History Of The Tube: In 1883, Edison discovered that electrons would flow from a suspended filament when enclosed in an evacuated lamp. Years later, in 1905, Fleming expanded on Edison’s discovery and created the “Fleming Valve”. -
Page 7: The Nature Of Tubes: Why (And When) To Replace Them
Important Information About Tubes and Tube Products (continued): The power tubes are the largest tubes used in an amplifier. These tubes convert the low-level, conditioned signal from the preamplifier into a level that is sufficient to drive the speakers. There are several types of power tubes available, each of which offers a different perfor- mance/sound characteristic. -
Page 8: The Importance Of Proper Biasing
Important Information About Tubes and Tube Products (continued): Whenever you replace the power tube(s): • Always have the amplifier’s bias voltage checked by a qualified service center. Improper bias voltage will cause degradation in performance and possibly damage the tubes and/or the amplifier. -
Page 9: Survival Tips For Tube Amplifiers
Important Information About Tubes and Tube Products (continued): Survival Tips For Tube Amplifiers: To prolong tube life, observe these tips and recommendations: • Match the impedance of your speaker cabinet(s) to your amplifier. Improper impedance matching will contribute to early tube degradation and may cause premature tube failure. •... -
Page 10: Suggested Settings
Some Suggested Settings Clean: Low-Volume Buzz: Bluesy Crunch: Crunchy Rhythm: Sparkly Clean: Uh-Oh!:... -
Page 11: System Block Diagram
SPEAKER REV1 REV2 Declaration Of Conformity Manufacturer: LOUD Technologies Inc. 16220 Wood-Red Rd. NE Woodinville, WA 98072, USA Product Name: Crate V50 Product Type: Audio Amplifier Complies with Standards: LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG Safety: EN60065 EMC: EN55013, EN55020, EN55022, EN55103, EN61000-3-2, &... -
Page 12: Technical Specifications
Weight 58 lb/26.2 kg The V50 is covered with a durable Tolex material. Wipe it clean with a lint-free cloth. Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish. Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this manual are subject to change without notice.
