Revision 2.2
2.4

Typical Card Power Requirements

Table 2-3
VDD (ripple: max, 60mV peak-to-peak)
Sleep
Read
Write
2.5

System Performance

All performance values for the SD Card in Table 2-4 are under the following conditions:
Voltage range 2.7 V to 3.6 V
Temperature -25° C to 85° C
Independent of the SD Card clock frequency
Table 2-4
Block Read Access Time
Block Write Access Time
CMD1 to Ready after
Power-up
Sleep to Ready
2.6

System Reliability and Maintenance

Table 2-5
MTBF
Preventative Maintenance
Data Reliability
Endurance
© 2004 SanDisk Corporation
Card Power Requirements (Ta=25°C@3.0V)
Value
250
65
75
System Performance
Timing
Reliability and Maintenance Specifications
>1,000,000 hours
None
<1 non-recoverable error in 10
100,000 write and erase cycles (typical)
2-2
Chapter 2 – Product Specifications
SanDisk SD Card Product Manual
2.7 V – 3.6 V
Measurement
uA
mA
mA
Typical
0.5 ms
0.5 ms
50 ms
1 ms
14
bits read
Average
Max
Max
Max
Maximum
100 ms
250 ms
500 ms
2 ms
12/08/04
