Page 1: Sandisk Corporation
Product Manual SanDisk uSSD 5000 Product Manual Revision 1 October 08 SanDisk Corporation Corporate Headquarters • 601 McCarthy Blvd. • Milpitas, CA 95035 Phone (408) 801-1000 • Fax (408) 801-8657 www.sandisk.com © 2008 SanDisk® Corporation October 2008, Document no. 80-36-03353... -
Page 2: Table Of Contents
2.9.3 uSSD-to-USB Adapter ... 13 2.10 Product Markings and Traceability ... 14 2.11 OS Support ... 15 2.12 Regulatory Compliance ... 15 Ordering Information ... 16 Disclaimer of Liability ... 17 © 2008 SanDisk® Corporation October 2008, Document no. 80-36-03353 Product Manual... - Page 3 Table 10: DC Characteristics for Full-Speed Operation (TA = 25°C) ... 11 Table 11: DC Characteristics for High-Speed Operation (TA = 25°C) ... 11 Table 11: Physical Dimensions ... 12 Table 12: OS Support ... 15 Table 13: Ordering Information ... 16 © 2008 SanDisk® Corporation October 2008, Document no. 80-36-03353...
-
Page 4: Introduction
Rugged and reliable, it is a fraction of the size and cost of a hard disk drive (HDD) in the 1 to 16 GB range. SanDisk adds high performance to the uSSD offering, based on an advanced controller that exemplifies the company’s years of USB expertise. -
Page 5: Features
Non-volatile storage (no battery required) USB 2.0 interface, certified by the USB organization (http://www.usb.org/home) Complies with Microsoft Vista Up to 16 GB of mass storage based on SanDisk’s reliable flash technology SLC flash and MLC flash-based configurations Fixed configuration (not removable) Low power consumption... -
Page 6: Scope
As such, systems that support uSSD 5000 now will be able to access future SanDisk Modules built with new flash technology without any need to update or change the host software. -
Page 7: Product Specifications
Contact discharge: Up to 4 KV (enclosed in a host) Air discharge: Up to 8 KV (enclosed in a host) PCB: 888-1 94V0 HK ASIC Packaging materials: 94V0 Flash packaging materials: 94V0 Labels: CM-100-SM, CM-200-WS October 2008, Document no. 80-36-03353 Product Manual No. of Sectors/ No. of Track Cylinders... -
Page 8: System Power Requirements
MLC 4GB, 8GB, 16GB MLC 2GB 2.5 mA 150 mA 150 mA 100 mA Vflash_protect Vflash_min Memory Binary 4.27 October 2008, Document no. 80-36-03353 Product Manual 5V +/- 10% IDD 2.5 mA 200 mA 200 mA 100 mA Unit 4.38 4.49... -
Page 9: System Performance
© 2008 SanDisk® Corporation Table 4: Performance Parameters 30 MB/sec 20 MB/sec 30 MB/sec 6 MB/sec 27 MB/sec 6 MB/sec 25 MB/sec 2.2 MB/sec 27 MB/sec 12 MB/sec 25 MB/sec 3.5 MB/sec Up to 60 MB/sec October 2008, Document no. 80-36-03353 Product Manual... -
Page 10: System Reliability
Wear-leveling 2.6.1 MTTF The reliability figure of merit most often used for electronic equipment is Mean Time To Failure (MTTF). SanDisk estimates MTTF using a prediction methodology based on reliability data for the individual components in SanDisk products. Component data comes from several sources: device life tests, failure analysis of earlier equipment, device physics, and field returns. -
Page 11: Endurance
USB1 Data(+) Key (no pin) 2.8.1 uSSD Connector Figure 1 illustrates the uSSD 2x5 device interface connector: Figure 1: uSSD 2x5 Connector Pinout © 2008 SanDisk® Corporation October 2008, Document no. 80-36-03353 Product Manual Signal +5VDC USB2 Data(-) USB2 Data(+) -
Page 12: Electrical Specifications
Input Levels USB Signals (D+): High Input Levels USB Signals ( D-): High Output Voltage USB Signals (D+, D-): High © 2008 SanDisk® Corporation Symbol data Symbol Iccs Symbol Iccs October 2008, Document no. 80-36-03353 Product Manual Unit °C -0.3 Unit Unit... -
Page 13: Physical Specifications
SanDisk uSSD 5000 Physical Specifications SanDisk offers the uSSD 5000 in 2 form factors: Standard profile Low profile Table 11 and Figure 2, Figure 3 and Figure 5 list the physical specifications and dimensions of the uSSD 5000. Table 11: Physical Dimensions... -
Page 14: Low Profile Configuration
5000 in an external desktop or laptop USB port. The adaptor is available at its leaded format for purchasing and its SKU is SDADP-UC-001 Figure 6: uSSD External USB Adapter © 2008 SanDisk® Corporation October 2008, Document no. 80-36-03353... -
Page 15: Product Markings And Traceability
WW week D Month day M Subcontractor code NNNNN Running serial number Firmware# - according to Bill of Material 54-90-XXXXX-CCCC Internal SanDisk subunit Number © 2008 SanDisk® Corporation /F low Profile with external LED October 2008, Document no. 80-36-03353 Product Manual... -
Page 16: Os Support
The system can also boot from the uSSD 5000, eliminating the need for additional components. Software packages for the supported operating systems can be downloaded from the SanDisk website, along with the relevant documentation. Operating System Windows XP Pro... -
Page 17: Ordering Information
1 megabyte (MB) = 1 million bytes; 1 gigabyte (GB) = 1 billion bytes. Some of the listed capacity is used for formatting and other functions, and thus is not available for data storage. © 2008 SanDisk® Corporation Standard Internal External Profile Profile October 2008, Document no. 80-36-03353 Product Manual Binary... -
Page 18: Disclaimer Of Liability
SanDisk shall not be liable for any loss, injury or damage caused by use of the Products in any of the following applications: Special applications such as military related equipment, nuclear reactor control,...
