Monogram Bon homme Richard Assembly Instructions Manual page 8

8
NOTE:
SAILYARDS ON ALL
SALES SHOULD BE
SQUARE WITH THE
DECK AND SQUARE
WITH A LINE FROM
STERN TO BOW.
95
FORE TOP
GALLANT
94
FORE LOWER
TOPSAIL
93
FORESAIL
BLACK
PAINT NOTE:
ALL YARDS AND EMBOSSED
ROPE TIES - DARK BROWN
PORT SIDE
FORE TOP MAST
91
INNER JIB SALE
1"
BLACK LINE
FIRST
90
SPRIT SALE
Kit 0388 - Page 8
SAIL / ANCHOR ASSEMBLY
98
MAIN TOP
GALLANT SAIL
BLACK LINE
92
STAYSAIL
3" PIECE OF
CHAIN
BLACK LINE TO CATHEAD
101
MIZZEN UPPER
TOPSAIL
C
B
A
MIZZEN CROSSJACK
33
ANCHOR BAR
RIGHT HALF
DARK BROWN
STARBOARD SIDE
BLACK LINE
BLACK LINE
60
RIGHT UPPER
MIZZEN
RATLINES
LEFT UPPER
RATLINES
A
MAIN LOWER
TOPSAIL
B
MAIN SAIL
81
MIZZEN
C
LOWER
YARD
TOPSAIL
DARK BROWN
ANCHOR BAR
LEFT HALF
DARK BROWN
ANCHOR
BLACK
BLACK LINE TO CATHEAD
61
MIZZEN
99
SPANKER
97
96
100
32
34
