- Page 1 INSTALLATION INSTRUCTIONS / OWNER S MANUAL PCD950R AM/FM HIGH POWER FLIP DOWN DETACHABLE FACE CD PLAYER...
- Page 2 Congratulations on your purchase of a Profile state-of-the-art single disc CD player. Your selection of a Profile car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your Profile CD player in a new system, you are certain to notice immediate performance benefits.
-
Page 3: Safety Precautions
To avoid the possibility of power, signal or speaker shorts, be careful not to allow the amplifier wires to come in contact with sharp edges. Use a grommet to protect the wire when running through the fire wall . PCD950R... -
Page 4: Care And Maintenance
ARE AND MAINTENANCE Cleaning the CD player When cleaning the vehicle, be sure not to get any water in or on the CD player. Clean only the exterior surface of the unit with a dry, clean soft towel using no chemical solvents. Operating in extreme temperatures Sometimes the unit will not operate in extreme, hot or cold temperatures. - Page 5 Do not stick paper or tape on the disc. Do not expose the disc to direct sunlight which can cause the disc to warp. Always store the disc in its case for protection. Scratched up discs will produce poor sound performance and cause CD player to skip. PCD950R...
- Page 6 LECTRICAL AND SIGNAL CONNECTIONS Before making the following connections, take time to look over the vehicle's wiring and determine the location and wires you will be connecting to. If you do not wish to cut or tap into the vehicles existing factory wiring, there are wiring kits available at your car audio retailer that will allow you to plug directly into the factory wiring harness.
- Page 7 (ON WITH IGNITION) BLUE AUTO ANTENNA FUSE GRAY WHITE FRONT LEFT FRONT RIGHT SPEAKER SPEAKER GRAY/BLACK WHITE/BLACK NOT USED NOT USED NOT USED NOT USED CAUTION! Tape unused wires so they do not short against other wires or chassis ground. PCD950R...
- Page 8 OUNTING THE CD PLAYER There are two different ways to mount the CD Player. In most Japanese vehicles you can use the factory mounting brackets, taking advantage of the ISO/DIN opening. If your vehicle does not have ISO/DIN opening, you can mount the CD Player using the supplied DIN sleeve and rear support bracket.
- Page 9 2 Then slightly push the plate to the left before attaching the right side hole into the right holder. 3 Finally push up the face plate until click sound is heard. PCD950R...
-
Page 10: Iso/Din Mounting
ISO/DIN MOUNTING If you own a Japanese vehicle, you can use the standard ISO/DIN mounting screw holes on the side of the CD player to attach to the existing factory mounting bracket, without using the provided DIN sleeve. Remove the factory ISO/DIN mounting bracket from the car along with the factory radio. Remove the factory radio from the bracket by unscrewing the two Phillips screws on each side of the radio paying close attention to their screw positions and saving the screws to mount the CD player. -
Page 11: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS PCD950R... -
Page 12: Flip Down Panel
1 POWER To turn ON the unit, press any button except the OPEN button. To turn OFF the unit, press the PWR button for more than 2 seconds. 2 FLIP DOWN PANEL Press the OPEN button to flip down the face plate. This will allow you to insert or eject a CD and also remove the face plate. -
Page 13: Preset Stations
BALANCE - Press the SEL button four times. Adjust the sound balance between left and right speakers using the VOL knob 5 . FADER - Press the SEL button five times. Adjust the sound balance between front and rear speakers using the VOL knob 5 . PCD950R... - Page 14 Press the SEL button for more than 2 seconds to display additional set of functions for adjustments, such as DSP, Beep On/Off, Seek 1 or 2 , 12 Hour/24 Hour, and Volume Last/Adjust. DSP - The unit is equipped with 4 preset equalization modes. Press the SEL button for more than 2 seconds to display DSP OFF.
- Page 15 Monaural (Mono) or Stereo mode can be selected for FM tuner s reception. For best quality sound, stereo mode should be selected. However, Mono mode can be selected to help the reception of distant radio stations. Press the ST button to select between Mono and Stereo modes. PCD950R...
- Page 16 20 CLOCK Press the CLK button to display the time on the LCD for 5 seconds. To adjust the time, press and hold the CLK button until the hour flashes and use the VOL 5 knob in the clockwise direction to adjust the hour. Press and hold the CLK button again until the minute flashes and use the VOL 5 knob in the counter clockwise direction to adjust the minute.
-
Page 17: Maintenance Of Remote Control
4) Gently push in the holder until securely locked into place. WARNING: Do not recharge, disassemble or dispose of in fire. Battery leakage may cause damage to the unit. To avoid the risk of accident, keep batteries out of reach of children. PCD950R... -
Page 18: Troubleshooting The System
The following chart will help in solving most problems that may occur. Should any problem persist after you have made these checks, please consult your nearest Profile retailer. Before going through this check list, refer back to the wiring and operating procedures. - Page 19 The bad. Radio station The signals in your listening Select stations manually and make sure the automatic area are weak. tuner is in the distant stereo mode. selection does not work. PCD950R...
-
Page 20: Specifications
PECIFICATIONS GENERAL Power Supply Requirements...........DC 12 Volts, Negative Ground || || || || || || Chassis Dimensions ...............7 (W) x 6 (D) x 2 (H) Tone Controls........................... Bass @ 100Hz..................+10dB / -10 dB Treble @ 10Khz..................+10dB / -10 dB Equalizer........................4 Presets Maximum Output Power..................50W x 4 RMS Output Power....................30W x 4 Maximum Current Consumption................15 Ampere... -
Page 21: Limited Warranty
One (1) Year from the date of sale to the original consumer purchaser. If this product is proven to be defective within this one year period, Profile will repair it when said product is returned, with a copy of the dated sales receipt, freight prepaid to Profile. -
Page 22: Warranty Repair Policy
4) Include a brief description of the problem or failure with the unit. 5) Include the return street address and daytime telephone number. 6) Allow 2~3 weeks for repair (this period includes shipping time). Send unit to: PROFILE CONSUMER ELECTRONICS, INC. 15060 SHOEMAKER AVE SANTA FE SPRINGS, CA 90670 TEL: (562) 404-9393...
