- Page 1 INSTALLATION INSTRUCTIONS / OWNER S MANUAL CD8200 AM/FM HIGH POWER DETACHABLE FACE CD PLAYER...
- Page 2 Your selection of a Profile car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your Profile CD player in a new system, you are certain to notice immediate performance benefits.
-
Page 3: Safety Precautions
To avoid the possibility of power, signal or speaker shorts, be careful not to allow the amplifier wires to come in contact with sharp edges. Use a grommet to protect the wire when running through the fire wall . CD8200... -
Page 4: Care And Maintenance
ARE AND MAINTENANCE Cleaning the CD player When cleaning the vehicle, be sure not to get any water in or on the CD player. Clean only the exterior surface of the unit with a dry, clean soft towel using no chemical solvents. Operating in extreme temperatures Sometimes the unit will not operate in extreme, hot or cold temperatures. - Page 5 Do not stick paper or tape on the disc. Do not expose the disc to direct sunlight which can cause the disc to warp. Always store the disc in its case for protection. Scratched up discs will produce poor sound performance and cause CD player to skip. CD8200...
- Page 6 LECTRICAL AND SIGNAL CONNECTIONS Before making the following connections, take time to look over the vehicle's wiring and determine the location and wires you will be connecting to. If you do not wish to cut or tap into the vehicles existing factory wiring, there are wiring kits available at your car audio retailer that will allow you to plug directly into the factory wiring harness.
- Page 7 (ON WITH IGNITION) BLUE AUTO ANTENNA FUSE GRAY WHITE FRONT LEFT FRONT RIGHT SPEAKER SPEAKER GRAY/BLACK WHITE/BLACK NOT USED NOT USED NOT USED NOT USED CAUTION! Tape unused wires so they do not short against other wires or chassis ground. CD8200...
- Page 8 OUNTING THE CD PLAYER There are two different ways to mount the CD Player. In most Japanese vehicles you can use the factory mounting brackets, taking advantage of the ISO/DIN opening. If your vehicle does not have ISO/DIN opening, you can mount the CD Player using the supplied DIN sleeve and rear support bracket.
- Page 9 1 Insert the face plate with the right side first. Angle in the right side of the plate to the unit. 2 Then push in the left side of the face plate until it snaps in place. FACE PLATE CD8200...
- Page 10 SO/DIN MOUNTING If you own a Japanese vehicle, you can use the standard ISO/DIN mounting screw holes on the side of the CD player to attach to the existing factory mounting bracket, without using the provided DIN sleeve. Remove the factory ISO/DIN mounting bracket from the car along with the factory radio. Remove the factory radio from the bracket by unscrewing the two Phillips screws on each side of the radio paying close attention to their screw positions and saving the screws to mount the CD player.
-
Page 11: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS CD8200... - Page 12 1 POWER To turn ON the unit, press any button except the button. To turn OFF the unit, press the button for more than 2 seconds. 2 DETACH FACE PLATE Press the button to detach the face plate. This will allow you to remove the face plate.
-
Page 13: Preset Stations
2 seconds to display DSP OFF. Then use 5 button to choose one of 4 following preset EQ s in the following order. When using preset EQ modes you will not have access to Bass and Treble settings. DSP OFF ROCK CLASSIC FLAT CD8200... -
Page 14: Repeat Play
BEEP - The beep sound when you press a button on the unit can be turned on or off. Press the SEL button for more than 2 seconds to display the DSP function. Press the SEL button again momentarily to display BEEP ON/OFF. Then use 5 button to turn on/off the beep sound. - Page 15 The reset button should be pressed when installation is complete and also when all buttons do not operate. 23 SECURITY LED Designed as a theft deterrent, the red LED will flash when the unit is turned off and face plate removed. CD8200...
-
Page 16: Troubleshooting The System
The following chart will help in solving most problems that may occur. Should any problem persist after you have made these checks, please consult your nearest Profile retailer. Before going through this check list, refer back to the wiring and operating procedures. - Page 17 The bad. Radio station The signals in your listening Select stations manually and make sure the automatic area are weak. tuner is in the distant stereo mode. selection does not work. CD8200...
-
Page 18: Specifications
PECIFICATIONS GENERAL Power Supply Requirements...........DC 12 Volts, Negative Ground || || || || || || Chassis Dimensions ..............7 (W) x 6 (D) x 2 (H) Tone Controls........................... Bass @ 100Hz..................+10dB / -10 dB Treble @ 10Khz..................+10dB / -10 dB Equalizer........................4 Presets Maximum Output Power..................35W x 4 RMS Output Power....................20W x 4 Maximum Current Consumption................10 Ampere... -
Page 19: Limited Warranty
One (1) Year from the date of sale to the original consumer purchaser. If this product is proven to be defective within this one year period, Profile will repair it when said product is returned, with a copy of the dated sales receipt, freight prepaid to Profile. - Page 20 4) Include a brief description of the problem or failure with the unit. 5) Include the return street address and daytime telephone number. 6) Allow 2~3 weeks for repair (this period includes shipping time). Send unit to: PROFILE CONSUMER ELECTRONICS, INC. 15060 SHOEMAKER AVE SANTA FE SPRINGS, CA 90670 TEL: (562) 404-9393...
