- Page 1 OM-814 150 448A 8November 1994 Processes Pulsed MIG (GMAW-P) Description Manual MIG Pulsing Control Pendant Visit our website at www.MillerWelds.com...
- Page 2 Welding Process Manuals such as SMAW, GTAW, GMAW, and GMAW-P. Miller Electric manufactures a full line of welders and welding related equipment. For information on other quality Miller products, contact your local Miller distributor to receive the latest full line catalog or individual catalog sheets.
-
Page 3: Section 1 - Safety Precautions - Read Before Using
SECTION 1 – SAFETY PRECAUTIONS - READ BEFORE USING som _nd_5/97 1-1. Symbol Usage Means Warning! Watch Out! There are possible hazards with this procedure! The possible hazards are shown in the adjoining symbols. This group of symbols means Warning! Watch Out! possible Y Marks a special safety message. - Page 4 ARC RAYS can burn eyes and skin. BUILDUP OF GAS can injure or kill. D Shut off shielding gas supply when not in use. Arc rays from the welding process produce intense D Always ventilate confined spaces or use visible and invisible (ultraviolet and infrared) rays that can burn eyes and skin.
-
Page 5: Principal Safety Standards
1-3. Additional Symbols For Installation, Operation, And Maintenance FIRE OR EXPLOSION hazard. MOVING PARTS can cause injury. D Do not install or place unit on, over, or near D Keep away from moving parts such as fans. combustible surfaces. D Keep all doors, panels, covers, and guards D Do not install unit near flammables. -
Page 6: Emf Information
1-5. EMF Information Considerations About Welding And The Effects Of Low Frequency 1. Keep cables close together by twisting or taping them. Electric And Magnetic Fields 2. Arrange cables to one side and away from the operator. Welding current, as it flows through welding cables, will cause electro- magnetic fields. -
Page 7: Section 2 - Specifications
SECTION 2 – SPECIFICATIONS 2-1. Pulse Control Specification Description Overall Dimensions Height: 8-1/4 in (210 mm); Width: 7-3/8 in (187 mm); Depth: 4-3/4 in (121 mm) Weight Net: 7 lb (3.2 kg); Ship: 12 lb (5.4 kg) Input Power Cord With Plug 20 ft (6.1 m) Additional Required Equipment Welding Power Source And Wire Feeder... -
Page 8: Section 4 - Operation
SECTION 4 – OPERATION 4-1. Function Of Controls Peak Current Control Use control to select peak current level during pulsed welding. Peak current level is defined as a percentage (25 – 100%) of maxi- mum output current of the welding power source in CC mode. -
Page 9: Section 5 - Troubleshooting
SECTION 5 – TROUBLESHOOTING 5-1. Welding Trouble Trouble Remedy No weld output. Be sure welding power source Power switch is On. Check welding gun and/or wire feeder according to its manual. No control of weld output. Check welding power source control settings (see Section 4-2). Be sure plug PLG3 is securely connected to Remote 17 receptacle on welding power source (see Section 3-1). -
Page 10: Section 6 - Parts List
SECTION 6 – PARTS LIST Dia. Part Mkgs. Description Quantity Complete Assembly ..145 697 CAPACITOR ............ - Page 11 Call LIMITED WARRANTY – Subject to the terms and conditions APT, ZIPCUT & PLAZCUT Model Plasma Cutting below, Miller Electric Mfg. Co., Appleton, Wisconsin, warrants Torches 1-800-4-A-MILLER to its original retail purchaser that new Miller equipment sold...
-
Page 12: Owner's Record
FAX: 44 (0) 1204-598066 www.MillerWelds.com Contact the Delivering Carrier for: File a claim for loss or damage during shipment. For assistance in filing or settling claims, contact your distributor and/or equipment manufacturer’s Transportation Department. PRINTED IN USA 2000 Miller Electric Mfg. Co. 6/00...
