Omega Freedom 200+2 Owner's Manual

"Protect Yourself And Your Investment"
OWNER'S MANUAL
Freedom 200+2
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT 2000
Introduction
Congratulations on your purchase of this vehicle security system. In learning to operate
your security system, please become familiar with the following three principal components:
the Remote Transmitter, the Red LED Status Light, and the Valet Switch.
The Remote Transmitter:
transmitters, but can learn up to 4 different transmitters. The transmitter has three buttons:
one large button and two smaller buttons. This system is pre-programmed, through a built-
in learning routine, to have the transmitter buttons work in the following configuration:
The large button is used to arm, disarm and panic the security system.
The small center button pressed for 2 seconds operates the trunk release feature.
The small lower button pressed for 2 seconds activates the 3rd Channel output or engages
the Anti-Carjacking feature, provided that it is programmed to operate.
The Valet Switch:
This switch is used to prevent automatic system functions, such
as Last Door Arming or Automatic Rearming, by placing the system into Valet Mode. The
Valet Switch is also used, in conjunction with the ignition key, to disarm the security system
in the event the transmitter becomes inoperable. This switch is also used in the procedure
for programming features and transmitters.
Each security system comes with two pre-learned
Page - 3

Table Of Contents

The Remote Transmitter ............................................................................................................ 3
The Valet Switch ........................................................................................................................ 3
The Red LED Status Light ......................................................................................................... 4
Transmitter Operations .............................................................................................................. 4
Active Arming The Security System Using The Transmitter .................................................... 5
Passively Arming The Security System With Last Door Arming .............................................. 6
Security System Armed And Activated .................................................................................. 7-8
Disarming The Security System ................................................................................................. 9
Automatic Rearming .............................................................................................................. 9-10
Remote Panic ............................................................................................................................ 10
The Valet Switch And Valet Modes .................................................................................... 10-11
Easy Valet ................................................................................................................................. 11
Valet Override - Disarming The Security System Without The Transmitter ........................... 11
Red LED Status Light - Security System Status ................................................................. 12-13
Shock Detection And Prewarn Circuit ..................................................................................... 14
Trunk Release And 3rd Channel Output .................................................................................. 14
Programmable Anti-Carjacking Protection .......................................................................... 15-16
Programmable Features ........................................................................................................ 17-21
Programming Transmitters .................................................................................................. 22-23
Multiple Vehicle Operation ...................................................................................................... 23
Limited Lifetime Warranty ........................................................................................ Back Cover
The Red LED Status Light: Informs you of the different conditions the system can
be in and also serves as a visual deterrent to break-ins and theft. Please spend time reviewing
this guide and to become familiar with your vehicle security system.
Transmitter
LED Light-
Illuminates when the
Transmitter is operating.
Small Center
Transmitter Button-
Pressing and holding this
button for 3 seconds can be
used to remotely open the
trunk (optional parts may be
needed).
Small Lower
Transmitter Button-
Pressing this button for 3 seconds will
engage the 3rd Channel Output or the programmable Anti-
Carjacking feature. Please see the sections describing these features.
Operations
Large Transmitter Button-
Pressing and releasing this
button will arm and disarm the
alarm, which optionally locks
and unlocks the doors. Press-
ing and holding this button
for 3 seconds will "Panic" the
alarm- sounding the siren,
flashing the exterior lights.
Page - 4
