JKP30SP
GE
27" Built-In Single Wall Oven
®
Undercounter Installation Dimensions
Gas or electric cooktops may be installed over this
oven. See cooktop installation instructions for cutout size.
See label on top of oven for approved cooktop models.
240V / 208V
Junction Box
25
Location
25" MIN.
25 1/4" MAX.
Allow 1"
unit overlap
27 5/8" MIN.
all edges
28 1/8" MAX.
3/4" Support
Platform Required
Must Support 150 Lbs.
For answers to your Monogram,
GE Profile
®
GE
®
appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
Gas or electric connections
for gas cooktop must be
located in an adjacent
accessible location to the right
5
36"
22" MIN.
Above
Typical
Support
Countertop
Platform
Height
24
or
™
service,
Sealed Burner Gas Cooktop Installation
(Pub. 1-G003 pg. 107) May 11, 1993
Sealed Burner Gas Cooktop
Installation Dimensions
90° Street el
2" Diameter hole (20-7/8"
45° Elbow
from front of countertop
to hole center)
Cabinet sides
Note: Oven is rated for use only under 30" standard or sealed burner gas
and selected 30" CleanDesign and Calrod
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
Electric wall ovens are not approved for installation with a plug
and receptacle. They must be hard wired in accordance with
installation instructions.
(Pub. 1-G003 pg. 107) May 11, 1993
Standard Burner Gas Cooktop
Installation Dimensions
5" To center of 2" diameter
hole from countertop
90° Street el
Cabinet sides
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating.
electric cooktops.
®
Specification Created 5/09
3-7/16"
To center of 2" diameter
hole from countertop
2" MIN. diameter hole
(23-1/4" from front
45° Elbow
surface of countertop)
All GE ranges are equipped with
Listed by
an Anti-Tip device. The installation
Underwriters
of this device is an important,
required step in the installation
Laboratories
of the range.
