- Page 1 Product Manual Seagate Laptop SSHD ® Standard models ST1000LX003 ST750LX006 Gen 2 100724266 Rev. B June 2013...
- Page 2 Publication number: 100724266, Rev. B June 2013 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Seagate Laptop SSHD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
-
Page 3: Table Of Contents
ONTENTS ......... . . 1 EAGATE ECHNOLOGY UPPORT... - Page 4 IGURES 5V S ......7 IGURE YPICAL TARTUP AND PERATION URRENT ROFILE SATA C .
-
Page 5: Seagate Technology Support Services
• Authorized Service Centers For information regarding Warranty Support, visit:http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/ For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Laptop SSHD Product Manual, Rev. B... -
Page 6: Introduction
NTRODUCTION ® This manual describes the functional, mechanical and interface specifications for the following Seagate Seagate Laptop SSHD model drives: Standard models ST1000LX003 ST750LX006 These drives provide the following key features: 5400-RPM spindle speed. 64MB buffer. 32GB NAND flash ... -
Page 7: Drive Specifications
The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. Table 1 Drive Specifications Summary ST1000LX003 ST750LX006 RIVE PECIFICATION... -
Page 8: Formatted Capacity
RIVE PECIFICATIONS Table 1 Drive Specifications Summary (continued) ST1000LX003 ST750LX006 RIVE PECIFICATION Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, nonoperating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) (below mean sea level, max) -
Page 9: Recording And Interface Technology
RIVE PECIFICATIONS ECORDING AND NTERFACE ECHNOLOGY Interface Serial ATA (SATA) Recording method Perpendicular Recording density 1894 Kb/in Track density 375 ktracks/in avg Areal density 705 Gb/in Spindle speed 5400 RPM +/- 0.2% Sustained data transfer rate 100 MB/s max I/O data-transfer rate 600 MB/s max HYSICAL HARACTERISTICS... -
Page 10: Power Specifications
RIVE PECIFICATIONS OWER PECIFICATIONS The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 2.7.1 Power consumption Power requirements for the drives are listed in the table in Table 4. Typical power measurements are based on an average of drives tested, under nominal conditions, at 25°C ambient temperature. -
Page 11: Conducted Noise
RIVE PECIFICATIONS 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure Figure 1 Typical 5V Startup and Operation Current Profile 2.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. ... -
Page 12: Power Management Modes
NVIRONMENTAL PECIFICATIONS This section provides the temperature, humidity, shock, and vibration specifications for Seagate Laptop SSHD drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. -
Page 13: Shock
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 14: Electromagnetic Immunity
To determine the warranty for a specific drive, use a web browser to access the following web page: http://www.seagate.com/support/warranty-and-replacements/ From this page, click on the “Verify Your Warranty” link. You will be asked to pro- vide the drive serial number, model number (or part number) and country of pur- chase. -
Page 15: Agency Certification
Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. Operation with noncertified assemblies is likely to result in interference to radio and television reception. -
Page 16: Environmental Protection
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 17: Configuring And Mounting The Drive
Figure Figure 2 Attaching SATA Cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Seagate Laptop SSHD drives support latching SATA connectors. SSHD P EAGATE APTOP RODUCT ANUAL... -
Page 18: Drive Mounting
ONFIGURING AND OUNTING THE RIVE RIVE OUNTING You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: Figure 3 ... -
Page 19: Serial Ata (Sata) Interface
For detailed information about the Serial ATA interface, refer to the Serial ATA: High Speed Serialized AT Attachment specification. OMPATIBILITY Seagate Laptop SSHD drives incorporate connectors which enable you to hot plug these drives in accordance with the Serial ATA: High Speed Serialized AT Attachment specification revision 2.0. This specification can be downloaded from www.serialata.org. This device requires a COMRESET from the host after a hotplug event. -
Page 20: Supported Ata Commands
ATA (SATA) I ERIAL NTERFACE There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. All used voltage pins (V ) must be terminated. ATA C UPPORTED OMMANDS Table 9... - Page 21 Table 9 Supported ATA commands ATA-standard commands names Command code (in hex) S.M.A.R.T. Disable Operations B0h/D9h S.M.A.R.T. Enable/Disable Autosave B0h/D2h S.M.A.R.T. Enable Operations B0h/D8h S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh S.M.A.R.T. Enable One Attribute Modification B0h/E0h S.M.A.R.T. Execute Offline B0h/D4h S.M.A.R.T. Free Fall Protection Host Interface S.M.A.R.T.
-
Page 22: Identify Device Command
Firmware revision: x.xx (8 ASCII character string, padded with blanks to end of string) 27–46 Drive model number: ST1000LX003 (40 ASCII characters, padded with blanks to end of string) ST750LX006 (Bits 7–0) 8010 Maximum sectors per interrupt on Read multiple and Write multiple... - Page 23 Description Value 60–61 Total number of user-addressable sectors ST1000LX003 = 0FFFFFFFh This field contains a value that is one greater than the total number ST750LX006 = 0FFFFFFFh user-addressable sectors. The maximum value that shall be placed in this field is 0FFFFFFFh. The 0FFFFFFFh value applies to all capacities over 137GB (see Section 2.1 for related information).
- Page 24 98-99 Streaming Performance Granularity 0000 100– Total number of user-addressable LBA sectors available ST1000LX003 = 1,953,525,168 (see Section 3.2 for related information) ST750LX006 = 1,465,149,168 These words are required for drives that support the 48-bit address- feature. Maximum value: 0000FFFFFFFFFFFFh.
- Page 25 ATA (SATA) I ERIAL NTERFACE Table 11 Bit Descriptions (continued) Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported.
-
Page 26: Set Features Command
ATA (SATA) I ERIAL NTERFACE 4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 27: Commands
) that eliminates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://www.seagate.com/support/downloads/seatools/. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature. - Page 28 NDEX errors 10 ESD 13 acoustics 9 EU 11 active mode 8 EU RoHS directive 12 Address 16 European Union (EU) requirements 11 agency certification 11 evice Configuration Identify 16 ambient temperature 5 Execute Device Diagnostics 16 areal density 5 ATA commands 16 Australia/New Zealand Standard AS/NZS3548 1995 11 FCC verification 11...
- Page 29 S.M.A.R.T. implementation 16 operating shock 9 safety certification 11 operating vibration 9 SATA ports 2 screws 14 Seagate Technology Support Services 1 physical characteristics 5 sectors 4 Physical organization 4 Security Disable Password 17 point-to-point 2 Security Erase Prepare 17...
- Page 30 UL60950-1 11 vibration 9 voltage dips, interrupts 10 voltage tolerance 7 warranty 10 weight 5 width 5 Write Buffer 17 Write DMA 17 Write DMA Extended 17 Write Long with Retries 17 Write Long without Retries 17 Write Multiple 17 Write Sectors 17 SSHD P EAGATE...
- Page 31 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100724266, Rev.
